Combined Temperature Altitude Humidity Testing Low-pressure Test Chamber

Summary

Altitude testing chamber is used for testing high temperature, low temperature, height, low and high cycle and temperature altitude test for products (components), parts and materials. The chamber can be used for the test of heat dissipation test sample and non heat dissipation test sample at the high and low temperature test. As to the test of heat dissipation test samples, the heating power should not exceed the refrigerating capacity of chamber. As a dynamist value, refrigerating capacity change with temperature change.

Standard

GB/T2423.2-2008 high-temperature test Bb

GB-2423.21-2008 Low pressure test M

GB/T2423.26-2008 high-temperature test/ Low pressure comprehensive test Z/BM

GJB150.2A-2009 Low pressure (height )test (Test procedureⅠ/Ⅱ/Ⅲ)

GJB150.2A-2009 High-temperature test

GJB150.6A-2009 temperature height test

Main features:

1.Outer wall material: High-quality carbon steel with static color spray
2. Inner wall material: SUS304 # matte stainless steel plate
3. Insulation materials: Rigid polyurethane foam insulation layer + glass fiber.
4. Door Single door: Heating wire was installed at the door frames to prevent condensation at low temperatures.
5. Observation window: Observation window W210*H270 mm, there are lights inside
6. Condensate water outlet: Equipped with condensing water and condensate drainage unit
7. Lead hole and terminal: Φ100mm*1 located on left side and sealed with glass sintering terminal(24-cell 10A) flange 1.
8. Gas valve: Gas valve used pressure relief by hand when power out
9. Sample holder: Two layers of stainless steel sample holder, load capacity 20kg/layer
10. Air Heater inside: Finned heat pipe-shaped stainless steel heater
11. Heater: High-quality nickel-chromium alloy wire electric heater, non-contact control (SRR).

Specification

Besides this, we have a lot of other chambers for your reference:

3-zone/ 2-zone Thermal Shock Chamber
Walk-in Constant Temp. And Humidity Chamber
Rapid Temp. Change Chamber
Precise Drying Test Chamber
Temperature/ humidity/ vibration three integrated Chamber
Precise Drying Chamber
Vacuum oven/ no oxidation oven
Air Exchange Type Aging Oven
Burn-in Room
Salt spray Chamber
Vibration Testing Machine( mechanical and electromagnetic)

FAQ

Q1: What is the Warranty for the accelerated aging machine?

A1: For the accelerated aging machine, we offer 1 year warranty service. If any quality problems on our side occurred in this period, we will send you the replacement and cover the cost of shipping and component parts.

Q2: What's the delivery term?

A2: Usually, it takes us 20 - 25 days after order confirmation to produce the equipment and a little bit longer for customization service. While if you are in urgent need, we can make a special arrangement to speed up the proceedings. Then we start the shipped by sea, by air freight or by air express.

Q3: What’s the payment term?

A3: T/T, L/C, and other payment terms could be negotiated.

Q4: Is it ok for customization service?

A4: Yes, the inner chamber dimensions, structure, color, some special parameters can be customized as per your specific request.

Specificaion for KU-1000S.pdf
