High Precision Expansion Clamp Pin 34g 59g For CNC Fixtures Workholding
High Precision Expansion Clamp Pin 34g 59g For CNC Fixtures Workholding
Specifications
Brand Name :
ADJIG
Model Number :
JYKZ-LS01
Place of Origin :
Chongqing, China
MOQ :
1
Price :
36 - 48 USD per item
Payment Terms :
L/C,T/T
Supply Ability :
Less than 10 pieces, shipped within 10 days. More than 10 items will be shipped within 30 days.
Delivery Time :
7-10 days
Packaging Details :
Carton/wooden crate
Tightening Torque Tapered Bolt (N.m) :
22
Expansion Diameter for Self-Processing :
0.1~0.15
Expansion Diameter :
0.6/0.8
Weight (g) :
34/59
Description

High Precision Expansion Pin for CNC Fixtures and Workholding Applications

Body:SUS630 HRC34

Tapered bolts:Steel (strength class 12.9) Oxygen resin coating

This High Precision Expansion Pin delivers exceptional accuracy for CNC fixtures and workholding applications. Engineered with a precision-ground taper and advanced expansion mechanism, it provides secure, vibration-free clamping with repeatable micron-level accuracy. The pin's unique design ensures uniform radial expansion for perfect concentricity, making it ideal for locating and securing components in machining operations. Manufactured from hardened, heat-treated steel, it withstands rigorous production environments while maintaining long-term dimensional stability. The quick-expansion feature dramatically reduces setup time while providing consistent clamping force, making it an essential component for high-volume precision machining of gears, bearings, and other critical components in milling, grinding, and turning applications.

Part Number D1 D2 H2 0
D-0.025		 H1 H M L W W1 Clamping Force
(KN)		 Tightening Torque
Body (N.m)
JYKZ-LS01 12 10.5 15 12 12 38 M12*1.75 11 5 6 8.4 30
JYKZ-LS02 16 12 16 16 16 45 M16*2 13 6 8 11 30

Part Number Tightening
Torque
Tapered Bolt
(N.m)		 Expansion Diameter for Self-Processing Expansion
Diameter		 Weight
(g)		 Suitable for Tapered bolts
JYKZ-LS01 22 0.1~0.15 0.6 34 JYKZ-LS01-TB
JYKZ-LS02 22 0.8 59 JYKZ-LS02-TB
