8 Pin Circular Push Pull Connectors, Female Pin Connector Replace LEMOS FGJ FHJ PHJ
8 Pin Circular Push Pull Connectors, Female Pin Connector Replace LEMOS FGJ FHJ PHJ
8 Pin Circular Push Pull Connectors, Female Pin Connector Replace LEMOS FGJ FHJ PHJ
8 Pin Circular Push Pull Connectors, Female Pin Connector Replace LEMOS FGJ FHJ PHJ
8 Pin Circular Push Pull Connectors, Female Pin Connector Replace LEMOS FGJ FHJ PHJ
8 Pin Circular Push Pull Connectors, Female Pin Connector Replace LEMOS FGJ FHJ PHJ
8 Pin Circular Push Pull Connectors, Female Pin Connector Replace LEMOS FGJ FHJ PHJ
8 Pin Circular Push Pull Connectors, Female Pin Connector Replace LEMOS FGJ FHJ PHJ
Specifications
Brand Name :
RAYMO
Model Number :
FNG.1B.302.CLAC52Z
Certification :
RoHS2.0, ISO:9001-2015, CE , SGS, REACH
Place of Origin :
SHENZHEN,CHINA
MOQ :
5 Piece/Pieces
Price :
Negotiable
Payment Terms :
Western Union, L/C, D/A, D/P, T/T
Supply Ability :
5000Pieces/ Week
Delivery Time :
5-7wds
Packaging Details :
Plastic Bag & Carton
Type :
Circular Push pull connectors
Shell Size :
1B
Contact no. :
2.3.4.5.6.7.8.9.10.14.16 pins
Insulator :
PPS/PEEK
IP RANKING :
IP50
Endurance :
5000 times push pull
Description

Replace LEMOS FGJ FHJ PHJ 1B Female 8 Pin Circular Push Pull Connector for ARRI Alexa Mini FGJ.1B.308

Parts Description

RAYMO P/N

Lemo P/N

RM-FGJ-1BC-308-JS52Z

FGJ.1B.308.CLAC52Z

  • 2 keys, 45 degrees, 1B shell size with 8 poles female solder contacts
  • Circular connectors Cable Straight Connector
  • Different shell size from 00B to 4B
Technical Characteristics

Temperature Range

- 40° C, +125° C

Resistance to vibrations

15 g [10 Hz - 2000 Hz]

Shell Material

Brass with chrome plated

Humidity

up to 95% at 60° C/140F

Shock Resistance

100 g [ 6 ms]

Salt spray corrosion test

>144hr

Climatical Category

50/175/21

Shielding (min)

> 75 dB [ at 10 MHz], > 40 dB [ at 1 GHz]

IP Rating

IP50

Endurance(shell)

5000 mating cycles
Main Features
Size/Series 0B/1B/2B/3B/4B (Metal (Mechanical Keying))
Shell Style/Model Ebow 90 degree plug
Keying 1 key (alpha=0, plug: male contacts, receptacle: female contacts)
Housing Material

Brass (chrome plated) shell and collet nut, nickel plated brass latch sleeve and

mid pieces
Configuration Brass (gold plated)
Insulator PPS
Contact Type Solder
Endurance (Shell) 5000 mating cycles
Temp (min) -40 deg
Temp (max) 125 deg C
Humidity (max) <=95% [at 60 deg C / 140 F]
Vibration 15 g [10 Hz - 2000 Hz]
Shock Resistance 100 g [ 6 ms]
Salt Spray Corrosion >144 hr
IP Rating 50
Company Intrce

RAYMO is a manufactuer that:

  • Focus on manufacturing & exporting various metal & plastic circular push pull connectors, cable assembly.
  • Can be 100% compatible with original LEMO • •FISCHER• HIROSE • BINDER •Industrial 38999
  • Series has RM-B, RM-K, RM-S, RM-F,RM-E,RM-HR10A, RM-P, RM-M4, RM-M12, RM-M16, BNC, B680,B423, 38999, 26482
  • CO, Form A, Form E for customer clearance
  • CE, ROHS, REACH, ISO:90001-2015, SGS Audited manufacturer
  • All the items can work normally after 5000times mating
Application
  • Medical like Diagnostic devices
  • Instrumentation like Test & measurement
  • Transport Avionics
  • Energy like Nuclear
  • Defense & Security like Communication systems
  • Broadcast like Studios and outside broadcasting
  • Extreme like Motorsports
Contacts ans shell size

Shell size Contacts no. (Both with Solder & PCB type)
RM-00 2 3 4 　 　 　 　 　 　 　 　 　 　 　 　
RM-0B 2 3 4 5 6 7 9 　 　 　 　 　 　 　 　
RM-1B 2 3 4 5 6 7 8 10 12 14 16 　 　 　 　
RM-2B 2 3 4 5 6 7 8 10 12 14 16 19 　 　 　
RM-3B 3 4 6 8/(6+2) 9(8+1) 10 12 14(13+1) 14 16 18 21 26 30 32
RM-4B 7 10 24 　 　 　 　 　 　 　 　 　 　 　 　
Dimensions and Keying

8 Pin Circular Push Pull Connectors, Female Pin Connector Replace LEMOS FGJ FHJ PHJ

8 Pin Circular Push Pull Connectors, Female Pin Connector Replace LEMOS FGJ FHJ PHJ

Certificate
  • CE
  • REACH
  • RoHS
  • ISO9000-2015
Advantages
  • Sample Free:1-2 PCS
  • Fast lead time: 3-5 work days if the QTY is under 200 PCS
  • Flexiblity payment way:T/T,PayPal,Westunion,Credit card
  • 24 hours service for clients
  • Competitive price & stable prction
  • Certified CE and RoHS
  • OEM/ODM/Cable Assemble
  • World-class customer service
RFQ

1. Are your company a professional manufacturer?
Raymo: Yes, we specialized in prcing circular connectors and cable assembly since 2010.Our factory is SGS audited manufacturer and served global customers for more than 9 years.
2. What is the MOQ?
Raymo: No MOQ limited, small order is accepted, all is depend on customer real needs.
3. Free sample:
Raymo: Available. Any needs, please contact us.
4. What about the delivery time?
Raymo: sample for 3-5 working days, mass prction for 5-7 working days.
5. What is your payment terms?
Raymo: 100% T/T deposit when customer place order.
6. Does your prct have any warranty?
Raymo: Yes, all of our connectors can work normally after 5000 cycles mating; our factory
has instruments to tested them before shipping.
Damage due to misuse, treatment and unauthorized modifications and repairs are not covered by our warranty.

If you couldn't find exact items you want,PLS kindly email us exact models you need, best price & each model specification details will be provided to you soon. Solve the original brand's high cost and long lead time!
