Ultra Low Quiescent Current Voltage Regulator 5 Volt LM2936Z-5.0
Ultra Low Quiescent Current Voltage Regulator 5 Volt LM2936Z-5.0
Specifications
Brand Name :
NSC
Model Number :
LM2936Z-5.0
Certification :
Original Factory Pack
Place of Origin :
Philippines
MOQ :
20
Price :
Negotiate
Payment Terms :
T/T, Western Union,Paypal
Supply Ability :
20000
Delivery Time :
1
Packaging Details :
please contact me for details
Features :
Ultra low quiescent current (IQ ≤ 15 µA for IO ≤ 100 µA
Features2 :
Fixed 5V, 50 mA output
Features3 :
Output tolerance ±3% over line, load, and temperature
Features4 :
Dropout voltage typically 200 mV @ IO = 50 mA
Features5 :
Reverse battery protection
Description

Ultra Low Quiescent Current Voltage Regulator 5 Volt LM2936Z-5.0

General Description

The LM2936 ultra-low quiescent current regulator features low dropout voltage and low current in the standby mode. With less than 15 µA quiescent current at a 100 µA load, the LM2936 is ideally suited for automotive and other battery operated systems. The LM2936 retains all of the features that are common to low dropout regulators including a low dropout PNP pass device, short circuit protection, reverse battery protection, and thermal shutdown. The LM2936 has a 40V maximum operating voltage limit, a −40˚C to +125˚C operating temperature range, and ±3% output voltage tolerance over the entire output current, input voltage, and temperature range. The LM2936 is available in a TO-92 package, a SO-8 surface mount package, and a TO-252 surface mount power package.

Features

Ultra low quiescent current (IQ ≤ 15 µA for IO ≤ 100 µA)

Fixed 5V, 50 mA output n Output tolerance ±3% over line, load, and temperature

Dropout voltage typically 200 mV @ IO = 50 mA

Reverse battery protection n −50V reverse transient protection

nternal short circuit current limit

Internal thermal shutdown protection

40V operating voltage limit

Ultra Low Quiescent Current Voltage Regulator 5 Volt LM2936Z-5.0

Ultra Low Quiescent Current Voltage Regulator 5 Volt LM2936Z-5.0
