Specifications
Model Number :
PS-PET-D80
Key Selling Points :
High Productivity
MOQ :
1SET
Delivery Time :
60-120 Days
Machine Type :
Pet Strip Production Line
Payment Terms :
T/T
Customization :
All parameters are fully customizable.
Price :
$19,800.00 – $25,000.00
Warranty :
1 Year
Supply Ability :
10 Sets/month
Certification :
CE ISO
Application :
Wire, PIPE, Sheet, Filament
Place of Origin :
Shanghai, China
Material :
PP PE LDPE HDPE
Brand Name :
CHLOE
Voltage :
220V-480V
Packaging Details :
Wooden Box
Description
ABi-Directional Palletizing System for PET Strapping PS-PET-D80
utomatic Palletizing System
Product Overview

The PS-PET-D80 palletizing system is a high-efficiency automatic palletizing solution specially developed for PET strapping roll production lines. It adopts a bi-directional dual-line palletizing mode with a maximum load of 80kg, suitable for strap rolls with an inner diameter of 406±1mm and an outer diameter of 600mm–1300mm. Equipped with Inovance control and inverter system and MCGS touch screen, the equipment features stable operation and simple human-machine interaction. With 15kW rated power and 0.6–0.8MPa working pressure, the system supports long-term continuous unmanned operation, effectively improving production efficiency and reducing manual stacking costs.

CE ISO Automatic Palletizing System High Productivity 480V Palletizing Solutions

Technical Parameters
Item Parameter
Overall Dimension 6200mm *20200mm * 7620mm
Total Weight Approx. 4000KG
Power Supply 380V±10%, 50Hz
Power 15kW
Working Pressure 0.6-0.8MPa
Applicable Strap Rolls Inner diameter 406±1mm, outer diameter 600mm–1300mm
Control System Inovance
HMI HMI
Max. Load 80kg
Max. Load 80kg
Palletizing Mode Bi-directional palletizing (two lines)
Key Features & Advantages
It realizes full automatic operation including pallet conveying, strap palletizing, partition placement and finished product output without manual intervention. With low power consumption and failure rate, simple operation and maintenance, it supports 24-hour continuous operation, replaces manual stacking, greatly reduces labor and operation costs, and realizes unmanned production.

CE ISO Automatic Palletizing System High Productivity 480V Palletizing Solutions

Application Scenarios
  • Winding finished PET straps on production lines
  • Intelligent strapping band production workshops
  • Compatible with robotic palletizing systems
Packaging & Shipping
  • Internal Protection: Secure movable internal parts with cable ties, reinforced with stretch film. Vulnerable areas wrapped with corrugated cartons or foam to prevent collision damage.
  • Outer Packaging: Complete equipment covered with thick PE protective sleeve, fastened tightly with strapping bands to resist impact and vibration. Packed in export-grade wooden cases.
  • Markings: Clear forklift positions and placement directions marked on cases with warning labels to prevent handling damage.
  • Accessories: Includes product certificate, packing list, and separately packed spare parts and components.
  • Final Inspection: Quality inspectors conduct final checks against export standards before shipment.
Frequently Asked Questions
Can you customize the machine? Such as voltage, air shaft size, machine color and other parameters.
Yes. We can customize voltage to suit local power supply, and adjust parameters including paper core size for air shafts, equipment color and more as per your requirements.
What specifications of strapping does the machine support?
This machine is suitable for PET strapping with width of 9-32mm and thickness of 0.5-1.4mm. We can also adjust the rewinder to match your product requirements.
How to select the right machine model?
We will recommend the most suitable model based on your PET strapping specifications, expected rewinding performance and on-site production conditions.
Do you provide installation and commissioning guidance?
We provide full English operation manuals and installation videos, along with free online technical support. Our technicians can also be arranged for on-site installation and commissioning upon your request.
Do you have a professional R&D team?
Yes. We have 16 years of experience in intelligent strapping machinery. All our machines and core components are independently developed. We also developed China's first fully automatic strapping rewinder with strong R&D capabilities.
How do you guarantee equipment quality?
Before delivery, our inspectors check every unit against factory standards on appearance, structure, electrics and safety, plus no-load operation. We also conduct customized tests as required. Test videos and inspection reports will be provided. You are welcome to inspect the machines on-site.
