EE64 EE65 PQ60 Planar Transformer High Power Density Low Leakage Isolation For DC DC Converter Power Supply
EE64 EE65 PQ60 Planar Transformer High Power Density Low Leakage Isolation For DC DC Converter Power Supply
EE64 EE65 PQ60 Planar Transformer High Power Density Low Leakage Isolation For DC DC Converter Power Supply
EE64 EE65 PQ60 Planar Transformer High Power Density Low Leakage Isolation For DC DC Converter Power Supply
EE64 EE65 PQ60 Planar Transformer High Power Density Low Leakage Isolation For DC DC Converter Power Supply
EE64 EE65 PQ60 Planar Transformer High Power Density Low Leakage Isolation For DC DC Converter Power Supply
EE64 EE65 PQ60 Planar Transformer High Power Density Low Leakage Isolation For DC DC Converter Power Supply
EE64 EE65 PQ60 Planar Transformer High Power Density Low Leakage Isolation For DC DC Converter Power Supply
Specifications
Model Number :
EE64 EE65 PQ60
Switching Frequency :
50–200 kHz for high-frequency power conversion.
MOQ :
10PCS
Delivery Time :
15-22 wark days
Output Current :
5–200 A, designed for high-current power conversion.
Temperature Rise :
≤40–50 K under specified rated operating conditions.
Packaging Details :
Small transformers: blister tray packaging + export cartons; Large transformers packed on wooden pallets. Custom packaging available upon request.
Payment Terms :
T/T
Operating Temperature :
-40°C to +125°C for demanding industrial environments.
Brand Name :
CHIPSEN
Rated Power :
1–5 kW, customizable for different power levels.
Place of Origin :
China
Output Voltage :
12–400 VDC for various DC-DC applications.
Price :
$20 - 50/ Piece,1000-10000pcs
Leakage Inductance :
Low leakage design helps reduce switching loss and EMI.
Certification :
UL/cUL Class B/F/H, VDE, CQC
Input Voltage :
200–800 VDC, customized to system requirements.
Supply Ability :
5000 pcs per day
Winding Configuration :
Custom turns ratio, winding structure and pin configuration.
Description
EE64 EE65 PQ60 Planar Transformer
High Power Density | Low Leakage | Reliable Isolation
Product Introduction

EE64, EE65 and PQ60 planar transformers are engineered for high-frequency, high-power-density power conversion applications. Their compact structure and optimized winding design reduce overall system size while maintaining stable electrical performance.

OEM/ODM customization available for voltage, current, frequency, power, winding configurations, and physical dimensions.

Electrical Parameter Recommended Range Common High-End Target
Rated Power 1–5 kW 2–4 kW
Switching Frequency 50–200 kHz 80–150 kHz
Input Voltage 200–800 VDC 380–800 VDC
Output Voltage 12–400 VDC 24 / 48 / 54 / 400 VDC
Output Current 5–200 A 20–100 A
Turns Ratio Customized according to Vin/Vout requirements
Primary Inductance Application-specific Typically hundreds of µH to several mH
Leakage Inductance ≤1–3 µH target ≤1–2 µH
DC Resistance (DCR) mΩ-level As low as practical
Isolation Voltage 2.5–4.0 kVAC 3.0 kVAC
Insulation Resistance ≥100 MΩ ≥500 MΩ
Temperature Rise ≤40–50 K ≤40 K
Operating Temperature -40 to +125 °C
Efficiency Target ≥95% 96–99%
Product Features
High Power Density – More power in a compact design
Low Leakage Inductance – Supports efficient and stable power conversion
High-Frequency Operation – Suitable for modern switching power systems
Reliable Isolation – Designed for demanding electrical isolation applications
Compact Design – Saves PCB and system space
Customizable – Designed to meet specific electrical and mechanical requirements
Applications
AI Data Centers & Server Power
Energy Storage & Solar Systems
Industrial Automation & Robotics
DC-DC Converters & Power Supplies
EV Charging Systems
Telecom & High-Power Electronics
Advantages
Product Advantages
High Power Density Low Leakage Compact Structure Stable Performance Custom Design
Company Advantages
25+ Years Manufacturing Experience – Founded in 2000
7,200㎡ Factory – Professional Production & Testing
OEM/ODM Support – Engineering Customization
UL • CQC • RoHS • ISO9001:2015 Certified
Built For High-Performance Power Electronics

Send us your specifications or drawing for a customized planar transformer solution.
