European Style Wood Pallet Block Feet Connecting Machine Pallet Legs Nailing Machine
European Style Wood Pallet Block Feet Connecting Machine Pallet Legs Nailing Machine
European Style Wood Pallet Block Feet Connecting Machine Pallet Legs Nailing Machine
European Style Wood Pallet Block Feet Connecting Machine Pallet Legs Nailing Machine
European Style Wood Pallet Block Feet Connecting Machine Pallet Legs Nailing Machine
European Style Wood Pallet Block Feet Connecting Machine Pallet Legs Nailing Machine
European Style Wood Pallet Block Feet Connecting Machine Pallet Legs Nailing Machine
European Style Wood Pallet Block Feet Connecting Machine Pallet Legs Nailing Machine
European Style Wood Pallet Block Feet Connecting Machine Pallet Legs Nailing Machine
European Style Wood Pallet Block Feet Connecting Machine Pallet Legs Nailing Machine
European Style Wood Pallet Block Feet Connecting Machine Pallet Legs Nailing Machine
European Style Wood Pallet Block Feet Connecting Machine Pallet Legs Nailing Machine
Specifications
Brand Name :
SH
Model Number :
SLDJ-1300-3, etc
Certification :
ISO9001,CE
Place of Origin :
Shandong Province, China
MOQ :
1 SET wood pallet pier automatic connecting nailing machine
Price :
US $7,800 - 12,400 / Set
Payment Terms :
T/T, Western Union
Supply Ability :
1000sets/year of wood pallet pier automatic connecting nailing machine
Delivery Time :
within 20 days
Packaging Details :
export packing or film wrapped container loading
Name :
European wood pallet pier automatic connecting nailing machine
Capacity :
600P/H
Power(w) :
1.5KW Servomotor
Block width :
60-150mm
Board Length :
600-1300mm or as customer needs
Nail gun :
Stanley BOSTITCH Stitch gun70mm*3
Nailing method :
1 nail, 2nails, 3nails, 4nails, 5nails
Condition :
New
Warranty :
1 Year
After-sales service provided :
commissioning and training, video technical support
Description

Automatic Euro Pallet Block Nailing Machine

– High-Efficiency Automated Pallet Production

Overview

The Automatic Euro Pallet Block Nailing Machine is a state-of-the-art industrial solution designed for high-speed, precision nailing in pallet manufacturing. With its fully automated program and advanced control system, this machine ensures smooth, efficient, and compact production, significantly enhancing workflow compared to traditional manual or semi-automatic methods.

For even greater productivity, the machine can be integrated with an automatic PALLET Nailing Machine and stacking system, enabling one-stop nailing and stacking production—reducing labor costs and optimizing output.

  • Technical data
Model SLDJ-1300-3
Block width 60-150mm
Board Length 600-1300mm
Nail gun Stanley BOSTITCH Stitch gun70mm*3
Air pressure 0.8MPA
Nail gun speed 4-8 s/time
Motor power 1.1KW Servomotor
Capacity 600P/H
Voltage 220V(Customized)
Operating mode Touch screen
Production mode Manual discharge/automatic pin pier
Machine size 2500*1800*2100mm
  • Images

European Style Wood Pallet Block Feet Connecting Machine Pallet Legs Nailing MachineEuropean Style Wood Pallet Block Feet Connecting Machine Pallet Legs Nailing Machine

European Style Wood Pallet Block Feet Connecting Machine Pallet Legs Nailing Machine

Applications & Benefits

  • Ideal for Euro pallet manufacturing, block pallet production, and custom pallet assembly.

  • Suitable for large-scale industrial operations requiring high-speed, repeatable nailing precision.

  • Reduces production time and costs while maintaining consistent, high-quality output.

Wood Pallet Production Line

Pallet block nailing machine + Automatic pallet nailing machine + Rotating machine + Logo Branding machine
+ Pallet corners cutting machine + Pallet turnover machine + Stacking/Palletizing machine + Conveyor
are connected into a production line.

European Style Wood Pallet Block Feet Connecting Machine Pallet Legs Nailing Machine

European Style Wood Pallet Block Feet Connecting Machine Pallet Legs Nailing Machine

Related Hot Selling Machines

  • Wooden pallet block nailing machine
Model PB200
Working mode Automatic feeding ,automatic nailing and cutting
Operating mode Touch screen control
Operational mode Pneumatic operation
Motor power 7.5KW,2.2KW*2,1KW
Raw material length 1000-3000mm
Block Length 40-200mm
Cutting height 40-120mm
Cutting width 40-100mm
Cutting blade 350-400mm
Number of planer 2
Nail quantity 1-3 pcs (adjustable)
Working Efficiency 5-6m3/day
Voltage 380V/3 Phase
Weight 1200Kg
Dimension 5400*1400*1600mm

European Style Wood Pallet Block Feet Connecting Machine Pallet Legs Nailing MachineEuropean Style Wood Pallet Block Feet Connecting Machine Pallet Legs Nailing Machine

  • Wood block multi-blade saw

Model BM-1250
Cutting Length 1250mm
Cutting Thickness 100mm
Cutting Width 200mm
Saw Diameter 355mm
Motor 30kw
Weight 1600kg

European Style Wood Pallet Block Feet Connecting Machine Pallet Legs Nailing MachineEuropean Style Wood Pallet Block Feet Connecting Machine Pallet Legs Nailing Machine
