HXEP400 Book Edge Digital Printing Machine Offering Continuous Printing With Automatic Print Head Movement Between Two Working Stations
HXEP400 Book Edge Digital Printing Machine Offering Continuous Printing With Automatic Print Head Movement Between Two Working Stations
HXEP400 Book Edge Digital Printing Machine Offering Continuous Printing With Automatic Print Head Movement Between Two Working Stations
HXEP400 Book Edge Digital Printing Machine Offering Continuous Printing With Automatic Print Head Movement Between Two Working Stations
HXEP400 Book Edge Digital Printing Machine Offering Continuous Printing With Automatic Print Head Movement Between Two Working Stations
HXEP400 Book Edge Digital Printing Machine Offering Continuous Printing With Automatic Print Head Movement Between Two Working Stations
Specifications
Weight :
650kg
RIP Software :
Ultraprint/Photoprint/PrintFactory/MainTop
Operation Environment :
Temperature 10-35℃; Humidity 30%-80%
Printing Size :
600×600mm(Dual Stations)
Power :
650W
Print Head :
Epson i3200×2, Micro-Piezoelectric, 2Sets
Brand Name :
HXCP
Supply Ability :
10 sets/month
Model Number :
HXEP400
Certification :
CE
Place of Origin :
China
Resolution :
Standard 720×1200dpi; Max 720×2400dpi
MOQ :
1 set
Printing Color :
4-color Printing, CMYK; 8-color(option)
Packaging Details :
Stretch Film with Wooden Case
Printing Speed :
600×600cm 720×1200dpi for 2 min(400 books/hour)
Delivery Time :
30 work days
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Voltage :
110-220V
Dimensions :
2680×1300×1830mm
Description

HXEP400 Book Edge Digital Printing Machine

HXEP400 Book Edge Digital Printing Machine Offering Continuous Printing With Automatic Print Head Movement Between Two Working Stations

Description

HXEP400 Book Edge Digital Printing Machine uses 2 sets of micro piezoelectric nozzle inkjet digital printing way to process the file, which can print any graphic patterns with 4 colors or 8 colors ink, on the edge of the hardcover book, notebook, sticky notes blocks, etc. Equipped with 2 working stations, when one station is printing, the operator can feed or discharge the books on the second station, when the first station finished printing, the print head will move to the second station to continue printing, so the operator can handle with the first station at the same time, non-stop ink jetting will avoid nozzle clogging.

Features:
Product Name: HXEP400 Book Edge Digital Printing Machine
Printing Technology: 2 sets of micro piezoelectric nozzle inkjet digital printing
Color Options: 4 colors or 8 colors ink for any graphic patterns
Applicable Materials: Hardbound books, notebooks, sticky notes blocks, etc.
Workstations: Equipped with 2 working stations for continuous operation
Non-Stop Operation: While one station is printing, operator can feed/discharge books on the second station
Automatic Switching: Print head moves to second station after first finishes printing
Nozzle Protection: Non-stop ink jetting avoids nozzle clogging
Keywords:

Book Edge Printing, Digital Edge Printer, Nozzle Inkjet Printing, Notebook Edge Printing, Hardcover Book Edge Printing, Sticky Notes Edge Printing

Support and Services:
The HXEP400 Book Edge Digital Printing Machine is a specialized piece of equipment designed for high-quality edge printing on hardcover books, notebooks, and sticky notes blocks using advanced micro piezoelectric nozzle inkjet technology. Our technical support and services team is available to assist with any questions or issues related to the operation, maintenance, and repair of the machine.
We offer a range of services to ensure that your machine is operating at its best, including:
  • Installation and setup assistance
  • Ongoing technical support via phone or email
  • Regular maintenance and servicing
  • Repairs and replacement parts
  • Training and education for machine operators
Our team of experienced technicians is dedicated to providing prompt and reliable support, so you can focus on your business operations with confidence. Contact us today to learn more about our technical support and services for the HXEP400 Book Edge Digital Printing Machine.

Parameters

Print Head Epson i3200×2, Micro-Piezoelectric, 2Sets
Printing Color 4-color Printing, CMYK; 8-color(option)
Printing Size 600×600mm(Dual Stations)
Printing Speed 600×600cm 720×1200dpi for 2 min(400 books/hour)
Resolution Standard 720×1200dpi; Max 720×2400dpi
RIP Software Ultraprint/Photoprint/PrintFactory/MainTop
Power 650W
Voltage 110-220V
Operation Environment Temperature 10-35℃; Humidity 30%-80%
Weight 650kg
Dimensions 2680×1300×1830mm

Products Show

HXEP400 Book Edge Digital Printing Machine Offering Continuous Printing With Automatic Print Head Movement Between Two Working Stations

HXEP400 Book Edge Digital Printing Machine Offering Continuous Printing With Automatic Print Head Movement Between Two Working Stations

HXEP400 Book Edge Digital Printing Machine Offering Continuous Printing With Automatic Print Head Movement Between Two Working Stations

Details

HXEP400 Book Edge Digital Printing Machine Offering Continuous Printing With Automatic Print Head Movement Between Two Working StationsHXEP400 Book Edge Digital Printing Machine Offering Continuous Printing With Automatic Print Head Movement Between Two Working StationsHXEP400 Book Edge Digital Printing Machine Offering Continuous Printing With Automatic Print Head Movement Between Two Working StationsHXEP400 Book Edge Digital Printing Machine Offering Continuous Printing With Automatic Print Head Movement Between Two Working Stations

FAQ

Q1 : Are you a trading company or a manufacturer?
A: We are a manufacturer, we supply the factory price with good quality, welcome to visit.

Q2: what's your guarantee or the warranty of the quality if we buy your machines?A: We can offer high quality machines with 1 year guarantee and supply life-long technical supports.

Q3: when can i get my machine after l paid?
A: The delivery time is based on the exact machine you confrmed.

Q4: How can i install my machine when it arrives?
A: We will send our engineers to your factory to install the machines and train your staff how to operate the machines.

Q5: what's your delivery time?
A: Depending on the type of machines, duration of 15 days to 60 days from the date ofcontract.

Q6: Do you have after-sales support?
A: Yes, we are happy to give advice adn we also have skilled technicians avaliable across the world, we need your machines running in order to keep your business running.

Q7: How about the spare parts?
A: After we deal down all the things. we will offer you a spare parts list for your reference.

Q8: Do you sell only standard machines?
A: No, most of our machines are built according to customers specifcations, using top components.

Q9: what will you do if the machien is broken:
A: Our machine'waranty period is 12 months, if the brokend parts can't repaird , we cansend the beyond the warranty period, we can send the new parts replace the broken partsfor free, but you need to pay the express cost. It is beyond the waranty period, we cannegotiate to solve the problems, and we supply the technical support for the whole life ofthe equipment.

Q10: Can you be responsible for transport?
A: Yes , please tell me the destination port or address, we have rich experience intransporting.
