Specifications
Brand Name :
New gabion
Model Number :
R-1688
Place of Origin :
China
Certification :
ISO9001, ISO14001
MOQ :
500 kgs
Price :
10-100
Payment Terms :
L/C, D/P, T/T, Western Union
Supply Ability :
10 ton
Packaging Details :
In roll, in carton water-proof
Product Name :
Razor Fencing Wire
Material :
Stainless steel, galvanized wire
Customized size :
Acceptable
Barb Length :
10-65mm
Number of Loops :
30-60
Out side diameter :
450mm-1000mm
Application :
Prison, Military, Boudary, Bank, Airport Ect
Number of Wires :
1
Type :
BTO-22
Enviroment :
Friendly
Installation :
Easy
Surface treatment :
Hot dipped galvanized or PVC coated
Description

Product Description:

Razor Fencing Wire is a type of security fencing system that provides high grade security against intrusions. It is made of steel wire, stainless steel and coated with a layer of protective coating of 40-300 microns thickness. It is designed with one wire with diameter of 2.0-4.0MM, and it is well known for its excellent anti-resistance and high grade security. This type of fencing is widely used as concertina wire fencing, wire mesh fencing, and razor wire fencing.

Customized Single Coil  Razor Wire Fencing BTO-22 stainless steel

Customized Single Coil  Razor Wire Fencing BTO-22 stainless steelCustomized Single Coil  Razor Wire Fencing BTO-22 stainless steel

Features:

  • Product Name: Razor Fencing Wire
  • Customized size: Acceptable
  • Material: Steel Wire, Stainless Steel
  • Razor type: Cross Type, Single Coil
  • Wire diameter: 2.0-4.0MM
  • Purpose: Prison fencing, Security fencing, Hot dipped galvanized wire mesh fencing
Customized Single Coil  Razor Wire Fencing BTO-22 stainless steel

Technical Parameters:

Parameter Value
Application Prison, Military, Boudary, Bank, Airport, etc.
Tensile Strength 550N/mm2
Number of Wires 1
Packaging Roll, In Carton, Water-proof
Barb Spacing 10-60mm
Colour Green, Silver
Type BTO-22, BTO-12, BTO-30,CBT-60
Barb Length 10-65mm
Wire diameter 2.0-4.0MM
Coating Thickness 40-300 Microns

Concertina Wire Coils Specification:
Type Outside Diameter No. of Loops Standard Length per Coil Notes
CBT-65 450mm 33 8M Single coil
CBT-65 500mm 41 10M Single coil
CBT-65 700mm 41 10M Single coil
CBT-65 960mm 53 13M Single coil
BTO - 10.15.22 500mm 102 16M Cross type
BTO - 10.15.22 600mm 86 14M Cross type
BTO - 10.15.22 700mm 72 12M Cross type
BTO - 10.15.22 800mm 64 10M Cross type
BTO - 10.15.22 960mm 52 9M Cross type

Applications:

New gabion's R-1688 Razor Fencing Wire is an excellent choice for security fencing. It is made of hot dipped galvanized wire and features excellent anti-resistance and high grade security. The barb spacing can be 10-60mm, and the barb width can be 10mm -40mm. It is available in both Cross Type and Single Coil razor types. PVC Coated Razor Fencing Wire is also available for added protection. It is an ideal solution for securing your property and ensuring the safety of your family and your assets.

Customized Single Coil  Razor Wire Fencing BTO-22 stainless steel

Customization:

New Gabion Razor Fencing Wire

Brand Name: New Gabion

Model Number: R-1688

Place of Origin: China

Type: BTO-22, BTO-12, BTO-30, CBT-60

Surface treatment: Galvanized, PVC Coated

Customized size: Acceptable

Advantage: Excellent Anti-resistance, High Grade Security

New Gabion Razor Fencing Wire is the perfect choice for prison fencing, razor wire fencing, and other security applications. It has a galvanized or PVC coated surface for maximum resistance to rust and corrosion. The type includes BTO-22, BTO-12, BTO-30, and CBT-60, and it is also available in custom sizes. It provides excellent anti-resistance and high grade security.

Customized Single Coil  Razor Wire Fencing BTO-22 stainless steel

Customized Single Coil  Razor Wire Fencing BTO-22 stainless steelCustomized Single Coil  Razor Wire Fencing BTO-22 stainless steel

Packing and Shipping:

Razor fencing wire is packaged in tightly sealed plastic spools or reels. These packages are then shipped by ground, air, or sea, depending on customer preference and location. To ensure the safety of the product during transport, the packages are wrapped in additional protective material such as bubble wrap and foam.

Customized Single Coil  Razor Wire Fencing BTO-22 stainless steel

Customized Single Coil  Razor Wire Fencing BTO-22 stainless steel
