50x50mm Sport Court Diamond Galvanized Steel Chain Link Fence
50x50mm Sport Court Diamond Galvanized Steel Chain Link Fence
50x50mm Sport Court Diamond Galvanized Steel Chain Link Fence
50x50mm Sport Court Diamond Galvanized Steel Chain Link Fence
Specifications
Brand Name :
XR
Model Number :
CLF-039
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 Roll
Price :
Negotiation
Payment Terms :
D/A, L/C, D/P, T/T, Western Union, MoneyGram
Supply Ability :
20000 Square Meters One Month
Delivery Time :
10-15 Days After Get Your Payment
Packaging Details :
1.chain link mesh fence fabric,there is on the pallet for the roll 2.Base on the metal pallet (plastic film on around,to keep the base clean) 3.Tie wire and fittings are in the small cartons
Product Name :
Steel Wire Mesh Fencing
Hole Shape :
Diamond
Application :
Sport Field,Garden,Park
Aperture :
50*50Mm,75*75Mm Or Customized
Weave Technique :
Cross Weave
Surface Treatment :
Hot Dip Galvanized/PVC Coated
Warranty :
3-10 Years Limited
Primary material :
Metal
Character :
Easy Install,Beauty
Feature :
Eco Friendly
Description

50x50MM Sport Court Galvanized Steel Wire Mesh Fencing

Product Description
1, wire: low-carbon zincification steel wire which meets all kinds of application.

2, plastic: imported hdpe plastic granule, excluded any recycled material to insure long life span and meet the requirement of environment.

3, synthesis: under 300 degree temperature, the wire and plastic compound so closely that no oxidation could be effected.

4, color: several pigments adding unique uv-resistant material to insure the color stability and could keep colors bright and clean for years.

5, Thickness: With the high temperature plasticizing extrusion and stable rotating speed, the thickness of plastic coated keep above 0.6mm.

6,Life span: high-density plastic granule, surface water absorption rate is 0%, general acid and alkali resistant, service life 3-5 years longer than ordinary plastic mesh fence

7, Craft: rotary hook weaving threading technology, optimization of mold design, to ensure that the product will never break when curved.

8, Maintainance: No needed to maintain, rain surface dust out.

9, Security: High strength rebound performance, even if crash is not easy to cause any harm to the athlete.

Product Breakthrough Characteristics
Low-carbon environmentally: all steel materials and accessories are galvanized first and then polyester powder painted, environmental protection and durability, can be used under the conditions of all weather

Product Spec: vertical post 70*70*3.0mm square tube
Cross post 50*50*3.0mm square tube
Iron strip 20*3mm fastened the fence
Lighting post 100*100*4.0mm square tube

Installation: the fence is assembled by modular accessories.

Characteristic: PE-coated mesh wire fence use low-carbon galvanized wire and plastified with high temperature, the thickness of plastic surface keep in above 0.6mm. Mixed into kinds of color powder and UV material to avoid color shade, the surface will keep bright and clean even used for years.

Sturdy Construction: the fence accessories use international 304 stainless steel carriage bolt M8*65, iron strip use self drilling screws M5.5*25

Technology introduction: hot galvanizing
Basic definition:

Melting the cleaned metal material or accessories into hot galvanizing to start physical and chemical reaction, it will form a layer of zinc

Hot galvanizing:

It is a developed and useful metal anticorrosive which is mainly used for metal structure facilities. Melting derusted metal into 500 celsius degrees galvanizing zinc to form a layer of zinc on the surface to antiseptic. The process of hot galvanizing: finished products acid-washing—water-washing—melt into galvanizing zinc—dry—rack plating—cooling—washing—polish—finish.

Product Benifits

It's strong because of the steel framework, concrete footers, and interlocked wire.
It's versatile because it can accommodate grade changes, has different gauges/grades, can be vinyl coated.
It is durable because of the galvanized or vinyl coating processes in manufacturing for natural elements.

50x50mm Sport Court Diamond Galvanized Steel Chain Link Fence50x50mm Sport Court Diamond Galvanized Steel Chain Link Fence
