Specifications
Brand Name :
HY
Model Number :
HY-GYTC-1
Certification :
CE
Place of Origin :
China Yixing
MOQ :
100 pieces
Price :
Negotiation
Payment Terms :
L/C, D/P, T/T, Western Union
Supply Ability :
10000 pcs per month
Delivery Time :
20-30 working days
Packaging Details :
wooden case
AL2O3 :
≥ 99.9%
product name :
Aluminum oxide ceramic tube and ceramic rod
color :
White
density :
3.85g/cm³
sintering temperature :
1750℃
hardness （HV) :
1600
size :
customization
Description

company specializes in the production of alumina industrial ceramic accessories, customized according to size, with an alumina content of 99%. It includes mechanical components, electronic insulation accessories, and ceramic products

Advantages of alumina ceramics:

1. Aluminum oxide ceramics have excellent insulation properties, with relatively low high-frequency losses but good high-frequency insulation properties;

2. Aluminum oxide ceramics have the characteristics of heat resistance, low coefficient of thermal expansion, high mechanical strength, and good thermal conductivity;

3. Aluminum oxide ceramics have characteristics such as chemical corrosion resistance and molten metal properties.

4. Aluminum oxide ceramics have excellent properties that are non combustible, rust resistant, sturdy, and not easily damaged, which are incomparable to other organic and metal materials;

5. Aluminum oxide ceramics have wear resistance, but their hardness is the same as that of corundum, and they can achieve Mohs hardness. The wear resistance is comparable to that of superhard alloys.

Physicochemical indexes of alumina solid rod:

Item Unit Typical Values
Physical Properties
Colour Ivory
Density g/cm3 3.85
Alumina Content % 99%
Gas Permeability 0
Water Absorption % 0%
Physical Properties
MONS’Hardness 82
Vickers Hardness(Hv50) Gpa(kg/mm2) 15.7(1600)
Flexural Strength(20℃) Mpa 330
Compressive Strength(20℃) Mpa 2000
Fracture Thoughness(20℃) Mpam1/2 4
Thermal Properties
Thermal Conductivity(20℃) W/(m.k) 27.5
Thermal Expansion Coeffcient 10-6/℃ 7.6
Thermal Shock Resistance △T℃ 200
Maximum Use Temperature ℃ 1650
Electrical Properties
Dielectric Strength KV/mm ＞12
Dielectric Conatant ε0 9-10
Dielectric Loss Angle(1MHz) 0.0002
Volume Resistivity(20℃) Ω.cm ＞10

source factories are complete in variety:

company specializes in the production of alumina industrial ceramic accessories, customized according to size, with a

company specializes in the production of alumina industrial ceramic accessories, customized according to size, with a

Machinery industry, electronics industry, electrical industry, chemical industry, medical industry, textile industry
