Higher Pressure Slurry Pump Spare Parts 6 Vane Impeller For Centrifugal Slurry Pump
Higher Pressure Slurry Pump Spare Parts 6 Vane Impeller For Centrifugal Slurry Pump
Higher Pressure Slurry Pump Spare Parts 6 Vane Impeller For Centrifugal Slurry Pump
Higher Pressure Slurry Pump Spare Parts 6 Vane Impeller For Centrifugal Slurry Pump
Higher Pressure Slurry Pump Spare Parts 6 Vane Impeller For Centrifugal Slurry Pump
Higher Pressure Slurry Pump Spare Parts 6 Vane Impeller For Centrifugal Slurry Pump
Higher Pressure Slurry Pump Spare Parts 6 Vane Impeller For Centrifugal Slurry Pump
Higher Pressure Slurry Pump Spare Parts 6 Vane Impeller For Centrifugal Slurry Pump
Specifications
Brand Name :
CNSME
Model Number :
F6058A05
Certification :
ISO/CE
Place of Origin :
CHINA
MOQ :
1 Piece
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
100 Pcs per Month
Delivery Time :
7 Working Days
Packaging Details :
Plywood Crate
Material :
A05 Ultra Chrome
Color :
Red
Use :
Centrifugal Impeller
Advantage :
Higher Pressure
Description :
Impeller
Part Code :
F6058A05
Description

Slurry Pump Parts 6 Vane Impeller Packed in Woden Crate Used for Centrifugal Slurry Pump

Introduction:

1. The below picture shows a 6-vane impeller in metal material, high chrome alloy A05, packaged in a wooden crate, and this impeller was shipped to Vladivostok, Russia.

Normally, if not requested other, we'll paint the impellers in Red color.

Higher Pressure Slurry Pump Spare Parts 6 Vane Impeller For Centrifugal Slurry PumpHigher Pressure Slurry Pump Spare Parts 6 Vane Impeller For Centrifugal Slurry Pump

2. Data Sheet of a 6-Vane impeller F6058 Slurry Pump 8/6E-

Pump
Model		 S×D
(inch)		 Allowable
Max. Power (kw)		 Material Clear Water Performance Impeller
Capacity Q Head
H(m)		 Speed
n(r/min)		 Max.Eff.
η%		 NPSH
(m)		 No. of
Vanes		 Vane Dia.
(mm)
Impeller m3/h l/s
SH/150E 8×6 120 A05 180-900 50-250 10-80 500-1300 75 2-9 6 545

3. Not only does SME offer the complete pumps, we also offer the spares for all series pumps, they include but not limited to:

-Impeller
-Metal Liner
-Rubber Liner
-Bearing Assembly
-Base
-Cover Plate & Frame Plate
-Others
Higher Pressure Slurry Pump Spare Parts 6 Vane Impeller For Centrifugal Slurry PumpHigher Pressure Slurry Pump Spare Parts 6 Vane Impeller For Centrifugal Slurry Pump


4. The pump parts can be made of high chrome, a wide variety of elastomers or the latest in ceramic materials for longer service life and higher efficiency.

Materials Offered:
-High Chrome Cast Iron
-Ductile Iron
-Stainless Steel
-Natural Rubber
-Specific Rubber
-Polyurethane

Higher Pressure Slurry Pump Spare Parts 6 Vane Impeller For Centrifugal Slurry PumpHigher Pressure Slurry Pump Spare Parts 6 Vane Impeller For Centrifugal Slurry Pump

Our services:

1. Quick Response. All messages or e-mail will receive a response within 8 hours
2. We can help to choose suitable pumps, if you are not sure which model of pump is suitable for you
3. We have a group of high quality technicians with rich experience that can solve all throughout the process.
4. Perfect after-sales. we will be responsible for the entire period of his life
5. OEM order. Many materials are available, both with high chromium content, rubber, stainless steel, etc.

Metal Pump Explosive View:

Higher Pressure Slurry Pump Spare Parts 6 Vane Impeller For Centrifugal Slurry Pump

Higher Pressure Slurry Pump Spare Parts 6 Vane Impeller For Centrifugal Slurry Pump

Higher Pressure Slurry Pump Spare Parts 6 Vane Impeller For Centrifugal Slurry Pump

Slurry Pumps Orders:

Higher Pressure Slurry Pump Spare Parts 6 Vane Impeller For Centrifugal Slurry Pump

Slurry Pump Impellers:

Higher Pressure Slurry Pump Spare Parts 6 Vane Impeller For Centrifugal Slurry Pump
