Opposite type Ultrasonic Flowmeter with Time Difference Measurement for 0~40 m/s Range and Corrosion Resistance
Opposite type Ultrasonic Flowmeter with Time Difference Measurement for 0~40 m/s Range and Corrosion Resistance
Specifications
MOQ :
1 Unit
Delivery Time :
10-15 working days
Packaging Details :
Neutral carton
Price :
USD2000-5000
Name :
Opposite type Ultrasonic Flowmeter
Model Number :
AG-CSF200
Supply Ability :
100 Unit/Week
Payment Terms :
T/T,Online order
Certification :
IOS9001, CE
Place of Origin :
Nanjing, China
Range :
（0~40）m/s
Brand Name :
JUGE
Description
Opposite type Ultrasonic Flowmeter
Overview
The AG-CSF200 ultrasonic flowmeter operates on the time difference method principle. This technology measures the difference in transmission time of sound waves traveling upstream versus downstream in the fluid, which has a precise mathematical relationship with gas flow velocity.
Key Features
  • Ultrasonic measurement with retractable probe casing prevents direct contact with gas flow, effectively avoiding naphthalene crystallization and coal tar adhesion
  • Time difference measurement unaffected by changes in gas composition, density, or moisture
  • Linear average flow velocity measurement ensures high stability
  • Extremely low measurement limit of 0.05 m/s with high accuracy
  • No moving parts minimizes maintenance requirements
  • LCD display adaptable to wide outdoor working temperatures
  • Automatic online zero calibration and span calibration
Technical Specifications
Parameter Specification
Measurement principle Ultrasonic time difference
Measurement range (0~40) m/s
Measurement accuracy ≤1.0 %
Resolution 0.1 m/s
Output Limit ≤0.1 m/s
Repeatability ±0.1 m/s
Zero drift ≤±0.1 m/s
Response time 5s (Adjustable)
Measuring medium Flue gas, coal gas
Working medium temperature range -40~450℃
Work pressure -6.1 Kpa~10.0 Kpa
Ambient temperature -40~60℃
Probe Material 304/316L stainless steel
Installation method Split type/Opposite type
Power supply 220V AC
Weight 18 kg
IP level IP65
