YG8 Tungsten Carbide Sleeve Bushing 16.41mm OD for Oil Field Pumps
YG8 Tungsten Carbide Sleeve Bushing 16.41mm OD for Oil Field Pumps
YG8 Tungsten Carbide Sleeve Bushing 16.41mm OD for Oil Field Pumps
YG8 Tungsten Carbide Sleeve Bushing 16.41mm OD for Oil Field Pumps
YG8 Tungsten Carbide Sleeve Bushing 16.41mm OD for Oil Field Pumps
YG8 Tungsten Carbide Sleeve Bushing 16.41mm OD for Oil Field Pumps
YG8 Tungsten Carbide Sleeve Bushing 16.41mm OD for Oil Field Pumps
YG8 Tungsten Carbide Sleeve Bushing 16.41mm OD for Oil Field Pumps
YG8 Tungsten Carbide Sleeve Bushing 16.41mm OD for Oil Field Pumps
YG8 Tungsten Carbide Sleeve Bushing 16.41mm OD for Oil Field Pumps
Specifications
Brand Name :
Kedel
Model Number :
KD-2001
Certification :
ISO9001:2015,SGS,
Place of Origin :
Sichuan, China
MOQ :
20 Piece/Pieces
Price :
$5.0 - $25.0 / Piece
Payment Terms :
T/T,L/C,Western Union
Supply Ability :
2000 pcs per months
Packaging Details :
box +carton
Material :
Tungsten carbide, metal, silicon carbide
Product name :
Bushing/bush/sleeve/tube, tungsten carbide bushinges&sleeves, motor shaft tungsten carbide metal bearing sleeve, Customized wear tungsten carbide bush /bearing bushing/thrust sleeve, Tungsten Carbide Sleeve Bushing
Type :
Sleeve, Precision Nonstandard Parts(ODM OEM Service), Tungsten Pipes, Power Tool Parts, cemented carbide bushing
Application :
used for water pump, Oil Field, oil pump and other pump, anti-corrosion
Features :
Excellent wear resistant and high hardness, Superior wear-resistance and impact toughness, Wear-resisting, abrasive resistance, corrosion resistance
Grade :
YG8 YG6 YG10X YN6 YN8 YN9, etc,
Description
Cemented Tungsten Carbide Anti-Corrosive Inlet Tubes Axle Sleeves Bushings For Submersibe Oil Field

Cemented carbide bushings sleeves is a mechanical part with high wear resistance, high strength and corrosion resistance manufactured by cemented carbide powder pressing and sintering and precision grinding. It is widely used in petroleum machinery, coal mining, chemical sealing, pump valve production and other fields.

Our advantages
  1. 100% Raw material: Bushings are produced with pure raw materials, which has the characteristics of long service life and stable performance.
  2. Maching: Bushings is processed by high-precision equipment:CNC machining center, grinding machine, milling machine, drilling machine,horizontal milling machine, chamfering machine, Metal Stamping ,CNC cutting machine etc.
  3. Multiple sizes available: We can provide bearing bushings different sizes, complete molds and short delivery time.7-10 days for samples .20-25 working days for mass productions
  4. Quality assurance: Unsurpassed Quality Standards.Our bushings sleeves bearings are designed and manufactured according to stringent quality standards that govern material selection, machining, surface finishing,inspection and packaging.
Common dimension reference
YG8 Tungsten Carbide Sleeve Bushing 16.41mm OD for Oil Field Pumps
Model No. Specification OD(D:mm) ID(D1:mm) Pore(d:mm) Length(L:mm) Step length(L1:mm)
KD-2001 01 16.41 14.05 12.70 25.40 1.00
KD-2001 02 16.41 14.05 12.70 31.75 1.00
KD-2001 03 22.04 18.86 15.75 31.75 3.18
KD-2001 04 22.04 18.86 15.75 50.80 3.18
KD-2001 05 16.00 13.90 10.31 76.20 3.18
KD-2001 06 22.00 18.88 14.30 25.40 3.18
KD-2001 07 24.00 21.00 16.00 75.00 3.00
KD-2001 08 22.90 21.00 15.00 75.00 3.00
KD-2001 09 19.50 16.90 12.70 50.00 4.00
KD-2001 10 36.80 32.80 26.00 55.00 4.00
Products Details
YG8 Tungsten Carbide Sleeve Bushing 16.41mm OD for Oil Field Pumps
Related products
  • Tungsten Carbide Bushings
  • Carbide Sleeves for centrifugal pump
  • Tungsten Drill Guide
  • Carbide Axle Shaft Sleeves
  • Carbide Plugs
  • Carbide Valve Balls.
  • Tungsten Carbide Valve Seats and Stems
  • Tungsten Carbide Oil and Natural Gas Wear Parts and Components
  • Tungsten Carbide Nozzles
  • Tungsten Carbide High Pressure Pump Components
  • Tungsten Carbide for -Flow Restrictors
  • Centrifugal Pump Components
  • Centrifugal Carbide Wear Tiles
Production Equipment
YG8 Tungsten Carbide Sleeve Bushing 16.41mm OD for Oil Field Pumps YG8 Tungsten Carbide Sleeve Bushing 16.41mm OD for Oil Field Pumps YG8 Tungsten Carbide Sleeve Bushing 16.41mm OD for Oil Field Pumps YG8 Tungsten Carbide Sleeve Bushing 16.41mm OD for Oil Field Pumps YG8 Tungsten Carbide Sleeve Bushing 16.41mm OD for Oil Field Pumps YG8 Tungsten Carbide Sleeve Bushing 16.41mm OD for Oil Field Pumps
Quality Control Equipment
YG8 Tungsten Carbide Sleeve Bushing 16.41mm OD for Oil Field Pumps YG8 Tungsten Carbide Sleeve Bushing 16.41mm OD for Oil Field Pumps YG8 Tungsten Carbide Sleeve Bushing 16.41mm OD for Oil Field Pumps YG8 Tungsten Carbide Sleeve Bushing 16.41mm OD for Oil Field Pumps YG8 Tungsten Carbide Sleeve Bushing 16.41mm OD for Oil Field Pumps YG8 Tungsten Carbide Sleeve Bushing 16.41mm OD for Oil Field Pumps
Product Exhibition
YG8 Tungsten Carbide Sleeve Bushing 16.41mm OD for Oil Field Pumps YG8 Tungsten Carbide Sleeve Bushing 16.41mm OD for Oil Field Pumps YG8 Tungsten Carbide Sleeve Bushing 16.41mm OD for Oil Field Pumps YG8 Tungsten Carbide Sleeve Bushing 16.41mm OD for Oil Field Pumps YG8 Tungsten Carbide Sleeve Bushing 16.41mm OD for Oil Field Pumps YG8 Tungsten Carbide Sleeve Bushing 16.41mm OD for Oil Field Pumps YG8 Tungsten Carbide Sleeve Bushing 16.41mm OD for Oil Field Pumps YG8 Tungsten Carbide Sleeve Bushing 16.41mm OD for Oil Field Pumps YG8 Tungsten Carbide Sleeve Bushing 16.41mm OD for Oil Field Pumps
Product tags

cemented carbide rods

,

silicon carbide bushings

,

steel spacers bushings
