HDMI 32'' 1920X1080 PCAP 400cd/m2 LED Gaming Monitor
HDMI 32'' 1920X1080 PCAP 400cd/m2 LED Gaming Monitor
HDMI 32'' 1920X1080 PCAP 400cd/m2 LED Gaming Monitor
HDMI 32'' 1920X1080 PCAP 400cd/m2 LED Gaming Monitor
HDMI 32'' 1920X1080 PCAP 400cd/m2 LED Gaming Monitor
HDMI 32'' 1920X1080 PCAP 400cd/m2 LED Gaming Monitor
HDMI 32'' 1920X1080 PCAP 400cd/m2 LED Gaming Monitor
HDMI 32'' 1920X1080 PCAP 400cd/m2 LED Gaming Monitor
Specifications
Brand Name :
rCloud
Model Number :
RCS-TM320-LED
Certification :
CE.FC,Rohs
Place of Origin :
China
MOQ :
1PCS
Price :
Negotiation
Payment Terms :
T/T, Western Union,Paypal, L/C
Supply Ability :
1000pcs per month
Delivery Time :
5-8 work days
Packaging Details :
Cartoon
Display Type :
16:9 Ratio, 32inch TFT-LCD
Active Area :
698.4 x 392.85 (mm)
Monitor Dimensions :
784.2 x 498.2 x 62.8 (mm)
Resolution :
1920 x 1080 @60Hz, 1080P
Support Colors :
16.7M
Video Input/Interface :
VGA/DVI/HDMI
Frequency :
37.9～80KHz / 60～75Hz
Power Supply :
DC12V±5%
Description

LED Deco Frame Touch Monitor Features:

Integrated with PCAP touch panel for the ultimate in image quality

Future generation panels phased-in without external changes

High quality panel with high brightness, contrast ratio and wide viewing angle

LED Halo Effects on around the Edge of the frame

Specifications

LCD Monitor
Model No. RCS-TM320-LED
Series LED Deco Slim(LED Bezel)
Display Type 16:9 Ratio, 32inch TFT-LCD
Active Area 698.4 x 392.85 (mm)
Monitor Dimensions (WxHxD) 784.2 x 498.2 x 62.8 (mm)
Suggested Resolution 1920 x 1080 @60Hz, 1080P
Support Colors 16.7M

Brightness (Typ.)

 Pure LCD Panel 400cd/m2
With Touch Monitor 330cd/m2
Response Time (Typ.) 14 ms
Viewing Angle (Typ.atCR＞10)) Horizontal (left/right) 89°/ 89°
Vertical (up/down) 89°/ 89°
Contrast Ratio (Typ.) 1000 : 1
Video Input/Interface VGA/DVI/HDMI
Frequency (H/V) 37.9～80KHz / 60～75Hz

Power Supply

Type: External

Display voltage: DC12V±5%

Input(line) voltage: AC100-240V,50-60Hz

Environment

 Operating Temp. 0～50°C
Operating RH 10%～90%
Storage Temp. -20～60°C
Storage RH 5%～90%
MTBF ≥30,000 Hours
LED Backlight Life Time (Typ.) ≥30,000 Hours
Weight(N.W/G.W) 18Kg /18.5Kg
Dimensions 784.2 x 498.2x 62.8(mm)
Power Consumption Stand by Power:≤1.5W/Operating Power:≤30W
Mount Interface

1. 100 x 200mm

2. Mount bracket, horizontal or vertical mount
OSD Control Buttons AUTO,+,POWER,-,MENU
Function Brightness,Contrast Ratio,Auto-adjust,Phase,Clock,H/V Location,Languages,Function,Reset
LED SMD 5050, 60 LEDs/m
LED IC / Power WS2812, 14.4W/m, 12V

Touch Screen
Touch Type 32inch Projected Capacitive Touchscreen
Touch Input/Interface USB
Response Time ≤10ms
Hardness Min.7H
Light Transmittance ≥85%
Support System XP,WIN7,WIN8,WIN10,Linux,Android
View Area 698.7 x 393.3 (mm)
Cover Glass Thickness 3.0±0.2 (mm)
Touch Test ≥50,000,00
Touch Controller EETI/ILI/ Siliconworks (optional)

HDMI 32'' 1920X1080 PCAP 400cd/m2 LED Gaming Monitor
