Type 261 Single Cartridge Mechanical Seal for Slurry Pumps Mixers
Type 261 Single Cartridge Mechanical Seal for Slurry Pumps Mixers
Type 261 Single Cartridge Mechanical Seal for Slurry Pumps Mixers
Type 261 Single Cartridge Mechanical Seal for Slurry Pumps Mixers
Type 261 Single Cartridge Mechanical Seal for Slurry Pumps Mixers
Type 261 Single Cartridge Mechanical Seal for Slurry Pumps Mixers
Type 261 Single Cartridge Mechanical Seal for Slurry Pumps Mixers
Type 261 Single Cartridge Mechanical Seal for Slurry Pumps Mixers
Type 261 Single Cartridge Mechanical Seal for Slurry Pumps Mixers
Type 261 Single Cartridge Mechanical Seal for Slurry Pumps Mixers
Specifications
Structure :
Single-End
Model Number :
Type 261
Temperature :
-20 ~ 150 ºC or less
MOQ :
1pc
Packaging Details :
Carton
Mediums :
Limewater and aqueous solutions containing chloride ions.
Supply Ability :
1000000/Month
Linear Speed :
10 m/s or less
Payment Terms :
T/T,Western Union,D/P,D/A,L/C
Specification :
Inner Diameter: 25 mm
Certification :
ISO9001
Materials :
SiC (Rotary) / SiC (Stationary) / Viton/EPDM/FFKM (Elastomers) / SS304/SS316/HC-276 (Springs) / SS304/SS316L/2507/2205 (Metal Parts)
Delivery Time :
15 working days
Pressure :
0 ~ 1.2 MPa
Place of Origin :
CHINA
Model NO. :
Type 261
Brand Name :
BESTSEAL
Description

Type 261 Single Cartridge Mechanical Seal for Slurry Pumps Mixers

Type 261

For: Slurry pumps, Side entry mixers

Single end, multiple springs, unbalanced cartridge mechanical seal with internal bearing kit sealed by 2 pieces of framework oil seals. Independent direction of rotation. Conforms to API682 standard. Inner diameter: 25 mm. Suitable for limewater and aqueous solutions containing chloride ions.

Materials

Rotary Face / Stationary Face / Elastomer / Spring / Metal Parts

SiC (Rotary) / SiC (Stationary) / Viton/EPDM/FFKM (Elastomers) / SS304/SS316/HC-276 (Springs) / SS304/SS316L/2507/2205 (Metal Parts)

Model Materials GA
Type 261 SiC (Rotary) / SiC (Stationary) / Viton/EPDM/FFKM (Elastomers) / SS304/SS316/HC-276 (Springs) / SS304/SS316L/2507/2205 (Metal Parts) —

Pressure: 0 ~ 1.2 MPa

Temperature: -20 ~ 150 ºC or less

Linear Speed: 10 m/s or less

Mediums: Limewater and aqueous solutions containing chloride ions.

Customization Available: Changes of materials for getting other operating parameters are possible. Contact us with your requirements.

BESTSEAL — Your Reliable Partner for Mechanical Seals

BESTSEAL Advantage:
15 years Focused in mechanical seal manufacturing
3 hours Quotation response only takes 3 hours
1 day Provide production assembly drawings
1 piece MOQ, One piece can also be produced
15-20 working days The production cycle only takes 15-20 working days
real-time Real time synchronization of production progress
