Specifications
Delivery Time :
15 working days
Secondary containment mating ring :
Tungsten carbide
Setting piece :
316 stainless steel, 304 stainless steel
Model Number :
Type 5840
Shaft sleeve :
Duplex stainless steel (wrought), CD4MCU-N cast, Super Duplex 28% Hard Chrome Iron (1.436/1.438), Alloy C-276
MOQ :
1pc
Packaging Details :
Carton
Cone Spring :
AFLAS® (TFE/P)
Soc. HD. capscrew :
Alloy steel (grade 12.9) zinc PLT
Supply Ability :
1000000/Month
Mating ring :
Silicon carbide, Tungsten Carbide (to 135mm/5.715")
Hex. HD. screws :
316 stainless steel
Elastomer :
AFLAS® (TFE/P)
Payment Terms :
T/T,Western Union,D/P,D/A,L/C
Primary ring :
Silicon carbide, Tungsten Carbide (to 135mm/5.715")
Pin :
316 stainless steel
Drive disc :
316 stainless steel
Brand Name :
BESTSEAL
Gland plate :
Duplex stainless steel (wrought), CD4MCU-N cast, Super Duplex 28% Hard Chrome Iron (1.436/1.438), Alloy C-276
Certification :
ISO9001
Primary ring carrier :
Duplex stainless steel (wrought), CD4MCU-N cast, Super Duplex 28% Hard Chrome Iron (1.436/1.438), Alloy C-276
Place of Origin :
CHINA
Drive collar :
316 stainless steel, 304 stainless steel, Duplex stainless steel
Spiral Retaining Ring :
302 stainless steel
Description
John Crane Type 5840 Single Cartridge Mechanical Seal for Slurry Pumps Agitators

Type 5840
Cost-effective Cartridge Slurry Seal

Our Type 5840 single-cartridge seal encompasses many of the advantages associated with heavy-duty seal design, encased in a cost-effective package.

Designed for the volume requirements associated with general mining processing duties, it contains robust primary and secondary seal face materials, making it the perfect general-purpose seal for slurry applications.

Features

  • Non-clogging, elastomer-encased cone spring applies constant spring load, eliminating dynamic O-rings.
  • Hydraulically balanced design with no sliding O-rings to cause hang-up.
  • Operates without flush, removing the need for circulation plans.
  • Operates with or without water quench.
  • Cartridge configuration allows for ease of installation.
  • Standard materials specified to meet the requirements of many duties; alternatives available where required.
  • Fully interchangeable with many designs already installed in the field.

BESTSEAL — Your Reliable Partner for Mechanical Seals

BESTSEAL Advantage:
15 years Focused in mechanical seal manufacturing
3 hours Quotation response only takes 3 hours
1 day Provide production assembly drawings
1 piece MOQ, One piece can also be produced
15-20 working days The production cycle only takes 15-20 working days
real-time Real time synchronization of production progress
