Specifications
Brand Name :
Y&G
MOQ :
Negotiation
Payment Terms :
L/C, T/T
Supply Ability :
8000MT per month
Delivery Time :
25~35days
Packaging Details :
Wooden cases, weave strips,as requirement.
Price :
Negotiable
Material :
2024, 2A16, 2A02,2A12,2A13,2A14...
Standard :
JIS H4080-2006
Application :
Rivets
OD :
2-2500mm
Wall thickness :
0.5-150mm or customised
Packing :
Exporting package/wooden box /as requirement.
Description

Hollow Aluminum Tube High Tensile Strength 2000 Series 2017 2024 Seamless Aluminum Tube for Structural 2 Inch

2000 series: 2024, 2A16(LY16), and 2A02(LY6) are representative of this series.2000 series Aluminum plates are characterized by higher hardness, of which the highest content of copper is about 3-5 %. 2000 series Aluminum rod is aviation aluminum and is not commonly used in conventional industries.

Production Description:

items 2000 Series 2017 2 inch Seamless Aluminum Tube
Surface treatment Mill finish, anodized, etc
Material 2A01,2A02,2A04,2A06,2A10,2A11,2B11,2A12,2A13,2A14,2A16,2B16,2A17,2A20,2A21,2A25,
2A49,2A50,2A70,2A80 and other series
Quality GB/T6893-2000,GB/T4437-2000, ASTM B241,JIS H4080-2006
Status T4 T5 T6 or other special status
Packing Protective film +plastic film or EPE +Kraft paper
Length Powder coating 6.5meters, anodizing 6.5 meters, mill finish 12 meters
Press Machine 500-4000 tons all together 64 press lines
Molding 1. Using our moulds, no fee;
2. Using customer drawing, opening mould, usually about 5 tons the molding fee is free;

Chemical Composition:

Grade Si Fe Cu Mn Mg Cr Ni Zn Ti Zr Al
2017 0.2-0.8 0.7 3.5-4.5 0.4-1.0 0.4-0.8 0.1 — 0.25 0.15 — Balance

Mechanical Properties:

Grade Temper Wall Thickness(mm) Tensile Strength(Mpa) Yield strength(Mpa) Elongation(%)

2017

 O All ≥245 ≥130 ≥12
H112 ≤18 ≥395 ≥260 ≥12
＞18 ≥395 ≥260 —


Applications:2017 aluminum alloy is the first to obtain industrial applications 2XXX alloy, the current narrow range of applications, mainly for rivets, general mechanical parts, structural and transport tool structures, propellers and accessories;

Mark: As required.
