19.05mm Hollow Aluminum Tube 7000 Series 7005 / 7075 With Good Welding Performance
19.05mm Hollow Aluminum Tube 7000 Series 7005 / 7075 With Good Welding Performance
19.05mm Hollow Aluminum Tube 7000 Series 7005 / 7075 With Good Welding Performance
19.05mm Hollow Aluminum Tube 7000 Series 7005 / 7075 With Good Welding Performance
19.05mm Hollow Aluminum Tube 7000 Series 7005 / 7075 With Good Welding Performance
19.05mm Hollow Aluminum Tube 7000 Series 7005 / 7075 With Good Welding Performance
19.05mm Hollow Aluminum Tube 7000 Series 7005 / 7075 With Good Welding Performance
19.05mm Hollow Aluminum Tube 7000 Series 7005 / 7075 With Good Welding Performance
19.05mm Hollow Aluminum Tube 7000 Series 7005 / 7075 With Good Welding Performance
19.05mm Hollow Aluminum Tube 7000 Series 7005 / 7075 With Good Welding Performance
Specifications
Brand Name :
Y&G
MOQ :
Negotiation
Payment Terms :
L/C, T/T
Supply Ability :
8000MT per month
Delivery Time :
25~35days
Packaging Details :
Wooden cases, weave strips,as requirement.
Price :
Negotiable
Material :
7075 , 7005 ,7001...
Type :
Seamless
Application :
Large heat exchangers
OD :
2~120mm
Wall thickness :
0.5mm~20mm or customised
Packing :
Exporting package/wooden box /as requirement.
Description

Hollow Aluminum Tube 7000 Series 7005 / 7075 with Good Welding Performance Seamless Aluminum Tube 19.05mm

7005: strength is higher than 7003 , good welding performance, heat treatment can be strengthened.

Production Description:

Item 7000 Series
Standard ASTM GB/T3190-2008
Material available 7000 Series:
Alloy 7001
Alloy 7075
Alloy 7005
Seamless Tube ,Pipe
Specifications Wall Thickness 0.5mm~20mm
Out Diameter 2mm~120mm
Length 3m,5.8m,6m,or as required
Surface Oxidation, electrophoresis coating, fluorine carbon spraying, powder coating, wood grain transfer, printing, mechanical drawing, mechanical polishing, sand blasting
Normal Anodizing thickness 8-12 micro
Package Export standard package: bundled wooden box or be required.

Chemical Composition:

Grade Si Fe Cu Mn Mg Zn Ti Cr Zr Al Other
7005 ≤0.35 ≤0.40 ≤0.10 0.2~0.7 1.0~1.8 4.0~5.0 0.01~0.06 0.06~0.20 0.08~0.20 Balance ≤0.05 each, ≤0.15 total

Applications: 7005 Aluminum alloy extrusion materials are often used in the manufacture of welding structures that require high strength and high fracture toughness, such as trusses, poles, and containers for transportation vehicles; Large heat exchangers, and parts that can not be fused after welding; It can also be used to make sports equipment such as tennis rackets and softball sticks.

Mark: As required.

19.05mm Hollow Aluminum Tube 7000 Series 7005 / 7075 With Good Welding Performance
