360 Car Wash Water Reclamation System With Water Flushing Pressure 120 Bar Touchless Car Wash Equipment
360 Car Wash Water Reclamation System With Water Flushing Pressure 120 Bar Touchless Car Wash Equipment
360 Car Wash Water Reclamation System With Water Flushing Pressure 120 Bar Touchless Car Wash Equipment
360 Car Wash Water Reclamation System With Water Flushing Pressure 120 Bar Touchless Car Wash Equipment
Specifications
Brand Name :
WINTAI
Model Number :
KP
Certification :
CE
Place of Origin :
China
MOQ :
1
Price :
To be discussed
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
100 sets/month
Delivery Time :
25
Packaging Details :
Standard export packaging
Electricity requirements :
380V/18.5Kw/50Hz
Installation dimensions :
8000*3700*3400(mm)
Maximum car wash size :
6000*2500*2050(mm)
Water pump motor(kw) :
380V/18.5kw
Flushing pressure :
80-120kg
Power consumption（kWh） :
0.5-0.8/per
Water consumption（L） :
100-200L
Material :
304 stainless steel
Rinse the car body once :
2 8 S
Color :
customizable
Logo :
customizable
Description
360 Car Wash Water Reclamation System With Water Flushing Pressure 120 Bar Touchless Car Wash Equipment
Product Overview
360 Car Wash Water Reclamation System With Water Flushing Pressure 120 Bar Touchless Car Wash Equipment 360 Car Wash Water Reclamation System With Water Flushing Pressure 120 Bar Touchless Car Wash Equipment
Built-in 360 Degree Rotating Arms
  • CAE computer aided simulation design ensures optimal nozzle placement and angle to prevent water hedging and maintain cleaning effectiveness
  • Intelligent distance calculation with safety and collision prevention functions
  • Equalized pressure, consistent distance, and uniform speed washing method
  • Complete 360° coverage for high pressure pre-wash, shampoo application, wax coating, and final drying
  • Enhanced rotation speed improved from one minute to just 30 seconds per rotation
Washing Modes
Fine Mode (5 minutes/car): Start → Chassis/Wheel Rim Flushing → Colorful High Foam Detergent Spraying → High Pressure Car Body Flushing → Low Foam Detergent Spraying → High Pressure Car Body Flushing → Wax Spraying → Wax Rain → Drying
Fast Mode (2 minutes/car): Start → Chassis/Wheel Rim Flushing → Colorful High Foam Detergent Spraying → High Pressure Car Body Flushing → Wax Spraying → Wax Rain → Drying
Technical Specifications
Product Name/Model KP360 Intelligent Version
Three Phase Electricity/Overall Power 380V/55Kw
Power Requirements 380V/22Kw/50Hz
Installation Requirements 8000×3800×3400 mm
Maximum Car Wash Size 6000×2500×2050 mm
Installation Costs Free Installation Guidance
Hanging Rail Length 8000 mm
Overall Weight/Volume 2650 kg / 13 m³
Central Processing Unit Embedded Central Processing Unit Industrial Control
360 Degree Rotary Flushing 304 Stainless Steel Rotating Arm
Main Water Pump Motor/Power 380V/18.5 kW
Fan Motor/Power 5.5 kW × 4 or 5.5 kW × 6
High Pressure Flushing Pressure 60-120 kg
Rinse Car Body Once 28 S
Car Wash Time Quick Washing: 2 min / Fine Washing: 5 min
Liquid Consumption Metering Pump / 20-50 ml
Power Consumption 0.5-0.8 kWh per wash
Water Consumption 100-200 L per wash
Additional Views
360 Car Wash Water Reclamation System With Water Flushing Pressure 120 Bar Touchless Car Wash Equipment 360 Car Wash Water Reclamation System With Water Flushing Pressure 120 Bar Touchless Car Wash Equipment 360 Car Wash Water Reclamation System With Water Flushing Pressure 120 Bar Touchless Car Wash Equipment
