360 Degree Rotating Arms Intelligent Brushless Car Wash Machine Fully Automatic
360 Degree Rotating Arms Intelligent Brushless Car Wash Machine Fully Automatic
360 Degree Rotating Arms Intelligent Brushless Car Wash Machine Fully Automatic
360 Degree Rotating Arms Intelligent Brushless Car Wash Machine Fully Automatic
Specifications
Brand Name :
WinTai
Model Number :
T9
Place of Origin :
Guangdong, China
MOQ :
1
Price :
$25,500.00/sets 1-1 sets
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
100 sets/month
Delivery Time :
25 days
Packaging Details :
Standard export packaging
Size :
3670mm*1330mm*1300mm
Warranty :
1
Output Power :
>1500W
Design Style :
New China-Chic
Model number :
T9
Max Vehicle Suitable :
6000*2500*2080mm
Water consumption :
65-200L/car
Electricity consumption :
0.4-1KW.H/car
Total Weight/volume :
≥3300kgs/≥8.5m
Type :
touch free type
Description
360 Degree Rotating Arms Intelligent Brushless Car Wash Machine Fully Automatic
Touch Free Car Washing Machine

This headache-free machine is designed to enhance your business operations with minimal maintenance requirements. We prioritize quality in every component, resulting in a robust system weighing 2.8 tons with a volume of 11 cubic meters.

Touch free car washing machine Self-service car washing machine Touchless car washing machine Brushless car washing machine
Optional Systems:
  • Waste water recycling system
  • Self-service payment system
  • Colorful lights system
Manufacturing Excellence
  • Laser Pipe Cutting Machine: All tubes and frames are precision-cut using laser technology
  • Laser Board Cutting Machine: Steel boards are cut with high precision laser equipment
  • CNC Bending Machine: Frames are bent directly without welding points for enhanced stability
Hot-Dip Galvanized Frame Construction

Our frames feature laser high-precision cutting, CNC bending, and 304 stainless steel high-strength screw fixation. This manufacturing process provides superior precision, stability, and safety compared to traditional welded frames.

Frame steel utilizes Q235 international standard profile with 4mm thickness. Surface treatment includes pickling, phosphating, and hot-dip galvanizing, with SGS salt spray test grade report achieving grade 10.

360 Degree Rotating Arms Intelligent Brushless Car Wash Machine Fully Automatic 360 Degree Rotating Arms Intelligent Brushless Car Wash Machine Fully Automatic
Special Features

Users can automatically set chemical consumption on the touch screen according to vehicle dirt levels.

Washing Modes
  • Fine Mode (5 minutes/car): Start → Chassis/wheel rim flushing → Colorful high foam detergent spraying → High pressure car body flushing → Shampoo spraying → High pressure car body flushing → Wax spraying → Drying → End
  • Fast Mode (2 minutes/car): Start → Chassis/wheel rim flushing → Colorful high foam detergent spraying → High pressure car body flushing → Drying → End
Technical Specifications
Item Parameters Function Remark
Machine Size (L*W*H)3670mm*1330mm*1300mmSelf-parking and detecting system√
Pump Size (L*W*H)1280mm*740mm*600mmDigital anti-collision system√
Chemical station size (L*W*H)1160mm*470mm*1350mmAll degree rotary high pressure flushing√
Max Vehicle Suitable6000*2500*2080mmChassis flushing√
Installation (L)-Frame Length7500mm~8000mmDetergent spraying√
Installation (W)3350mm~3686mmColorful/high foam detergent spraying√
Installation (H)3300mm-3400mmWax spraying system√
Total Weight/volume≥3300kgs/≥8.5m³Built-in automatic drying system√
Power Requirement380V/25KW or other voltageLED indication light guide system√
Air Switch100AOperation permission setting function√
Total Power13KW/24.5KWSelf-service payment system√
Water Pump Motor Power18.5KW/pressure 100Bar, 100-100 Bar Adjustable, SimensVoice Prompts function√
Fan Motor Power5.5KW/set x4setsCar washing counting function√
Horizontal Motor Power0.55KW asynchronous frequency conversion speed regulationAntifreeze system√
Cross Motor Power1KW digital servo motorOil-free system√
Rotation motor Power1KW digital servo motorEqual pressure anti-blocking nozzle√
Chemical Proportion Motor Power0.37KWSafe alarm system√
Central Processing unit PLCIndustrial intelligent digital control systemAutomatic Standby function√
Drive systemVariable frequency speed control+digital servo driver
Inspection systemIntelligent three-dimensional detection system
Running speed27 seconds/360 degree one circleSelf-service payment system.
Water consumption65-200L/carColorful Lights.
Electricity consumption0.4-1KW.H/carWater Recycle System.
√ Standard | . Optional
360 Degree Rotating Arms Intelligent Brushless Car Wash Machine Fully Automatic 360 Degree Rotating Arms Intelligent Brushless Car Wash Machine Fully Automatic 360 Degree Rotating Arms Intelligent Brushless Car Wash Machine Fully Automatic 360 Degree Rotating Arms Intelligent Brushless Car Wash Machine Fully Automatic 360 Degree Rotating Arms Intelligent Brushless Car Wash Machine Fully Automatic
Optional: Sewage Purification and Recycling System
360 Degree Rotating Arms Intelligent Brushless Car Wash Machine Fully Automatic
Optional: Self-Service Payment System
360 Degree Rotating Arms Intelligent Brushless Car Wash Machine Fully Automatic
