Automatic Magnetic Palletizer for Food and Beverage Canning Lines

High-Efficiency Magnetic Palletizing for Metal Cans and Jars

High-speed canning lines require reliable end-of-line container stacking without scratching or denting can bodies. Manual handling creates severe bottlenecks and increases product damage rates.

The LWT magnetic palletizer utilizes permanent magnetic suction heads driven by synchronized servo lifting motors. Our heavy-duty magnetic stacking head lifts full can layers securely to eliminate container dropping risks. It handles filled tin cans, empty beverage cans, and glass jars with metal closures.

Leading food and beverage producers across Europe, Latin America, the Middle East and Asia rely on LWT canning automation. We have engineered specialized magnetic palletizing systems for high-output Saudi and Russian canning facilities. Every layer stays stable and perfectly aligned. That reliability protects your bottom line.

Engineered for Continuous Stability, Layer Control, and Fast Changeover

Continuous food packaging lines demand consistent layer placement and gentle container handling. This magnetic stacking system provides dependable performance under round-the-clock plant schedules:

Servo Precision Lifting: Delivers smooth vertical acceleration curves with ±0.5 mm positioning repeatability.

High-Capacity Stacking: Handles full can layers with steady throughput reaching 2–4 layers/min (customizable).

Quick Format Change: Operators switch between varied can diameters and tier heights in minutes via the touchscreen.

Sanitary Industrial Build: Built with a rigid structural steel frame and 2 mm thick "304" stainless steel contact components.

Integrated safety interlocks and vacuum pad sensors prevent dropped containers during power interruptions. Clean mechanical movements keep lines running.

Technical Specifications & Operating Capabilities

Our magnetic palletizing system delivers dependable performance tailored to diverse canning line capacities. Standard engineering parameters include:

• Stacking Capacity: 2–4 layers/min (customizable)
• Gripping & Lifting Mechanism: Permanent magnetic suction head with servo vertical motion (customizable)
• Maximum Stacking Height: ≤1800–2000 mm per pallet (customizable)
• Maximum Pallet Payload: 1000–1500 kg per pallet (customizable)
• Standard Pallet Dimensions: 1100 * 1100 mm / 1200 * 1200 mm * 150 mm (customizable)
• Infeed Conveyor Height: 650–1100 mm (customizable)

All operating parameters adapt to specific can heights, layer counts, and downstream transport requirements. Exact dimensions integrate smoothly into your layout.

Seamless Integration into Complete Canning and Packaging Lines

An automated magnetic palletizer reaches maximum productivity when integrated into a unified canning line. LWT engineers full turnkey layouts from initial container feeding to finished pallet transport.

Upstream, this palletizer connects with a Can Seaming Machine and Automatic Retort Sterilizer for processed food cans. Downstream discharge connects with an Automatic Labeling Machine or directly into an Automatic Pallet Wrapping Machine for secure stretch wrapping.

LWT delivers fully synchronized turnkey canning solutions that optimize plant footprint and reduce labor overhead. Line integration remains clean and dependable.

Frequently Asked Questions

Q: How does LWT prevent scratching on printed or coated metal can surfaces?

A: Our magnetic suction head utilizes food-grade wear-resistant buffer pads across the magnetic surface. The industrial controller regulates gentle landing velocities to prevent friction marks. Our specialized magnetic tooling preserves lithographed graphics on premium canned food packaging.

Q: What company capabilities and factory testing support does LWT provide?

A: Founded in 2009, LWT maintains an experienced R&D engineering division and over a decade of canning automation expertise. We welcome clients to our Shanghai manufacturing facility for on-site Factory Acceptance Testing (FAT). We also offer live high-definition video testing prior to shipment.

Q: What warranty terms and after-sales services are included?

A: All LWT magnetic palletizers come with a comprehensive 1-year warranty covering mechanical and electrical components. Our service team provides 24/7 remote technical support, overseas installation and commissioning, and rapid spare parts dispatch worldwide.

Q: Can this magnetic palletizer handle both empty and filled tin cans?

A: Yes. We configure magnetic field strength and gripper tooling for empty can depalletizing or filled can palletizing. Switching between container heights is easily managed through stored recipe programs.

Connect with LWT Canning Automation Specialists

Contact LWT today to receive a customized magnetic palletizer layout and detailed quotation within 24 hours. Our canning automation engineers will review your container specifications and production targets to deliver an optimized packaging solution.
