60DE Cam Indexing Drive Overview

The HONEPAN 60DE cam indexing drive is a compact right-angle cam indexer whose shaft output suits small rotary indexing mechanisms and light positioning tasks. It brings the same precision cam architecture to space-constrained instruments and bench-top automation, delivering accurate intermittent motion in a very small package.

Despite its miniature footprint, the 60DE retains the backlash-free cam-and-roller design of our full range, so fast cycling does not compromise positional accuracy. Its low-noise operation makes it ideal for clean, quiet work environments.

Working Principle

A rotating globoidal cam engages needle rollers on the right-angle output shaft, converting continuous input rotation into precise intermittent indexing. The cam's dwell section mechanically locks the shaft at each stop, ensuring repeatable positioning without electronic feedback.

Key Features

• Compact right-angle body for tight installations
• Shaft output couples easily to gears and dials
• Smooth, backlash-free indexing at high cycling rates
• Low-noise operation for clean work environments
• Precision-ground cam profile for repeatable stops
• Sealed design resists dust and light contamination
• Flexible station count from 2 to 8 positions

Technical Specifications

Note 1: Input shaft GD² is the dwell value. Note 2: C1~C5 values are allowable values at a safety factor of 2.

Why Choose HONEPAN 60DE

• Precision cam indexing in a compact right-angle package
• High cycling speed with low noise
• Reliable mechanical positioning without electronics
• Cost-effective for light automation tasks

Applications

The 60DE fits light rotary mechanisms, small feeders, and compact positioning stages in electronics, medical device, and instrumentation equipment.

Customization & Support

We provide custom shaft options, station counts, and matched micro-motor solutions. Contact us for selection assistance and technical support.

FAQ — Frequently Asked Questions

1. What is a cam indexer and how does it work?

A cam indexer converts continuous motor rotation into precise intermittent (stop-and-go) rotary motion. A hardened globoidal cam engages needle roller followers on the output turret, advancing it one station per revolution and mechanically locking it during dwell — no electronic feedback, sensor, or brake is required.

2. What is the output type of the 60DE?

The 60DE features a Shaft (right angle) output, making it easy to mount dial plates, flanges, or fixtures directly. Its compact footprint integrates smoothly into automated assembly, packaging, and inspection workstations.

3. How many indexing stations are available?

The 60DE supports 2, 3, 4, 6, 8 (customizable). We can also custom-grind the cam profile for a different station count or dwell angle to match your exact production sequence.

4. What is the indexing accuracy?

Indexing accuracy is ±30 Sec. with repositioning accuracy of ±4 arcsec (±2 arcsec). This mechanical precision is maintained over a long service life thanks to the backlash-free cam-and-roller design.

5. What load and torque can it handle?

Please refer to the Technical Specifications table above for the allowable radial/axial loads (C1–C3), bending force (C4), input torque (C5), GD² (C6), and weight. For safety, all C1–C5 values are rated at a safety factor of 2.

6. Can you customize stations, dwell angle, or mounting interface?

Yes. We customize the number of stations, driving angle, dwell angle, cam curve, and mounting interface to your requirements. Send us your dial diameter, station count, payload, and cycle time for a tailored recommendation.

7. What is the MOQ, lead time, and warranty?

MOQ is 1 piece. Standard models ship within 4–20 days, and custom configurations may take longer. Every unit carries a 1-year warranty, a 60,000-hour design service life, and lifetime technical support.

8. What industries use HONEPAN cam indexers?

Our cam indexers are widely used in automated assembly, filling and capping, packaging, inspection, and machining systems across the automotive, electronics, hardware, pharmaceutical, and food industries.
