Specifications
Model Number :
HR-SH10MM6
Blade Material :
High Speed Steel
PLC Screen Size :
1.5-inch
Inner Core Cable Number :
2 cores, 3 cores, 4 cores,5cores
Packaging Details :
Carton
Inner Core Front Strip :
1-20mm
MOQ :
1
Delivery Time :
Within 5 Working Days
Outer Front Strip Length :
1-210mm
Wire Length Range :
1～9999mm
Max Conduit Inside Diameter :
￠11mm
Price :
1400
Inner Core Rare Strip :
1-20mm
Outer Rare Strip Length :
1-100mm
Payment Terms :
L/C,D/A,Western Union,T/T,D/P
Weight :
45KG
Length Accuracy :
± (0.002xL)mm
Display :
5 Inch PLC Screen
Supply Ability :
200
Machine Size :
56*46*37cm
Voltage :
220V
Blade Type :
Tungsten Steel
Certification :
CE /ISO
Output :
1000-1200pcs/hour
Place of Origin :
China
Wire Spe :
￠2-10mm (Round sheath wire)
Processing Speed :
1200 cables per hour
Brand Name :
JunSheng
Power :
550W
Wire Types :
PVC, Teflon, Braided, Fiberglass wire
Description
550W Power High Speed Steel Blade Wire Strip Machine with 1000-1200pcs/hour Output for Wire Harness Processing
Download Technical Specifications (HR-SH10MM6.xlsx)
  • 1.5-inch PLC touch screen control with precise length tolerance and adjustable cutting and peeling parameters
  • Multi-core wire compatibility (2/3/4/5 cores) with outer sheath stripping capability: 210mm front end, 100mm back end; inner sheath stripping: 20mm both ends
  • Low power consumption reduces energy usage while processing up to 1200 cables per hour
  • Compatible with various wire types: PVC, Teflon, Braided, and Fiberglass wires
  • Tungsten steel blades ensure clean, complete stripping of hard wire insulation without deformation or scratches to solid copper cores
