Touch Screen Automatic Cable Stripping Machine High Precision Wire Cutting Stripping Machine 550W
Touch Screen Automatic Cable Stripping Machine High Precision Wire Cutting Stripping Machine 550W
Touch Screen Automatic Cable Stripping Machine High Precision Wire Cutting Stripping Machine 550W
Touch Screen Automatic Cable Stripping Machine High Precision Wire Cutting Stripping Machine 550W
Touch Screen Automatic Cable Stripping Machine High Precision Wire Cutting Stripping Machine 550W
Touch Screen Automatic Cable Stripping Machine High Precision Wire Cutting Stripping Machine 550W
Touch Screen Automatic Cable Stripping Machine High Precision Wire Cutting Stripping Machine 550W
Touch Screen Automatic Cable Stripping Machine High Precision Wire Cutting Stripping Machine 550W
Touch Screen Automatic Cable Stripping Machine High Precision Wire Cutting Stripping Machine 550W
Touch Screen Automatic Cable Stripping Machine High Precision Wire Cutting Stripping Machine 550W
Touch Screen Automatic Cable Stripping Machine High Precision Wire Cutting Stripping Machine 550W
Touch Screen Automatic Cable Stripping Machine High Precision Wire Cutting Stripping Machine 550W
Touch Screen Automatic Cable Stripping Machine High Precision Wire Cutting Stripping Machine 550W
Touch Screen Automatic Cable Stripping Machine High Precision Wire Cutting Stripping Machine 550W
Specifications
Payment Terms :
L/C,D/A,Western Union,T/T,D/P
Weight :
45KG
Length Accuracy :
± (0.002xL)mm
Display :
5 Inch PLC Screen
Supply Ability :
200
Machine Size :
56*46*37cm
Voltage :
220V
Model Number :
HR-SH10MM6
Blade Material :
High Speed Steel
Screen Control :
1.5-inch PLC touch screen
MOQ :
1
Delivery Time :
Within 5 Working Days
Outer Front Strip :
1-210mm
Wire Length Range :
1～9999mm
Max Conduit Diameter :
￠11mm
Price :
1450
Inner Core Rare Strip :
1-20mm
Outer Rare Strip :
1-100mm
Inner Core Cable :
2 cores, 3 cores, 4 cores,5cores
Packaging Details :
Carton
Inner Core Front Strip :
1-20mm
Brand Name :
JunSheng
Power :
550W
Wire Types :
PVC, Teflon, Braided, Fiberglass
Blade Type :
Tungsten steel
Certification :
CE /ISO
Output :
1000-1200pcs/hour
Place of Origin :
China
Wire Spe :
￠2-10mm (Round sheath wire)
Core Condition :
Free of deformation or scratches
Description
High Precision Wire Cutting & Stripping Machine with 1000-1200pcs/hour Output and 5 Inch PLC Screen
Download Technical Specifications (HR-SH10MM6.xlsx)
Advanced 2-in-1 machine combining precision wire cutting and stripping capabilities for home appliance wire harness production.
  • 1.5-inch PLC touch screen control with precise length tolerance and adjustable cutting and peeling parameters
  • Multi-core wire compatibility (2/3/4/5 cores) with front-end stripping up to 210mm and back-end stripping up to 100mm for outer sheath, plus 20mm front and back stripping for inner sheath
  • Low power consumption design reducing energy usage while processing up to 1200 cables per hour
  • Compatible with various wire types including PVC, Teflon, Braided, and Fiberglass wires
  • Tungsten steel blades ensure clean, complete stripping of hard wire insulation without deformation or scratches to solid copper cores
Exhibition
Touch Screen Automatic Cable Stripping Machine High Precision Wire Cutting Stripping Machine 550W
Package And Shipping
Touch Screen Automatic Cable Stripping Machine High Precision Wire Cutting Stripping Machine 550W
Quality Certifications:
Touch Screen Automatic Cable Stripping Machine High Precision Wire Cutting Stripping Machine 550W
