Long Insulating Length 3.5M Anti-interference High Voltage Telescopic Electroscope 220V
Long Insulating Length 3.5M Anti-interference High Voltage Telescopic Electroscope 220V
Long Insulating Length 3.5M Anti-interference High Voltage Telescopic Electroscope 220V
Long Insulating Length 3.5M Anti-interference High Voltage Telescopic Electroscope 220V
Specifications
Brand Name :
SHENGHONG
Model Number :
XHYD-220
Certification :
ISO
Place of Origin :
MADE IN CHINA
MOQ :
5pcs
Price :
negotiation
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
50pc/day
Delivery Time :
10 days after payment
Packaging Details :
carton
Product Name :
Fiberglass Telescopic Hot Stick
Effective insulation distance :
3.5m
Length ( including packing ) :
1m
Weight (including packing ) :
2.0kg
Wave Form :
Square wave
Output Ac Voltage :
3.0V
Description

Long Insulating Length 3.5M Anti-interference High Voltage Telescopic Electroscope 220V

Voltage levels: 10 kv, 35 kv, 110 kv, 220 kv, 330 kv, 500 kv ac voltage, for direct contact to check the electricity.
Starting voltage, high voltage electrode is formed by metal sphere, should not be placed within the space of 1 m other objects, the electroscope electrode contact with a grounded ac voltage of high voltage electrode contact, rising high voltage electrode voltage, when the electroscope signal "voltage existence", such as "light" instruction, record the starting voltage, such as the voltage between (0.15 ~ 0.4) times the rated voltage, thought through.

Data Sheet

Model XHYD-10 XHYD-35 XHYD-110 XHYD-220 XHYD-500
Voltage 10KV 35KV 110KV 220KV 500KV
Effective insulation distance 0.90m 1.20m 2.80m 3.50m 6.15m
Length ( including packing ) 0.60m 0.60m 1.00m 1.00m 1.30m
Weight (including packing ) 1.1kg 1.2kg 2.0kg 2.1kg 2.5kg
Wave Form Square wave Square wave Square wave Square wave Square wave
Output Ac Voltage 2.5V 2.7V 3.0V 3.5V 3.5V
Frequency 50Hz±1Hz 50Hz±1Hz 50Hz±1Hz 50Hz±1Hz 50Hz±1Hz

Long Insulating Length 3.5M Anti-interference High Voltage Telescopic Electroscope 220V
