Specifications
Brand Name :
Hongli
Model Number :
35
Certification :
CE
Place of Origin :
Dongguan
MOQ :
1 set
Price :
40,000$-55,000$
Payment Terms :
T/T, L/C
Supply Ability :
10 set per month
Delivery Time :
20-30 days
Packaging Details :
wooden packing
Name :
PTFE Extruder Machine Cable
screw :
35mm
capacity :
60kg/h
inlet size :
0.3-3mm
output size :
0.5-5mm
motor power :
11KW
motor brand :
siemens
inverter brand :
Yaskawa
length of machine :
21 meters
extruder material :
HC-276, Hastelloy alloy steel,
Description

FPA PTFE High Temperature Insulation Wire Hastelloy Alloy Steel Extruder Machine

About us:
Our factory has been manufacturing extrusion lines for over 20 years ,we also produce copper buncher, cable twisting machine, copper drawing machine.Until now we have exported some production lines to Pakistan, iraq,Tunisia, Algerial, Egypt, India, Afghanistan,Nigeria, Sudan, we are still working on other country,

Main brands for our machine

- Motor: SIEMENS, DONGGUAN MOTOR,
- Inverter: YASKAWA, INOVANCE, SIEMENS,
- PLC: Siemens
- Touch Screen: Siemens
- Low-voltage electrical components: Schneider
- Bearings: NSK or SKF
Characteristics:
It is suitable for the production of fluoroplastics such as FEP (polyfluoroethylene propylene, also known as F46), FPA (oxidized alkoxyethylene resin) and ESFE (also known as F40).

Screw barrel: all adopt the new No. 3 steel GH113 (same as American GDA material) for corrosion resistance and high temperature resistance or imported Hastelloy gold steel.

Machine head: special non-adjustable machine head or adjustable machine head made of new No. 3 gold steel GH113 or Microdia machine head and vacuum device imported from Switzerland.

Heating system: high temperature resistant cast copper alloy heater is used.

Quality control: Equipped with external diameter detection feedback device, Japanese TAKIKAWA concave-convex tester to control the outer diameter of the product in the whole process, British BETA water capacitance tester, high-frequency spark machine and concentricity and other process parameters.


Product Parameters
Machine model NHF-20 NHF-25 NHF-30
Applicable cable Coaxial cable Coaxial cable RGB178
Inlet diameter 0.025/7 0.03/7 0.86
Finished diameter 0.2 0.25 1.08
production capacity 50MPM 80MPM 300MPM
Dimensions 10*1*2m 12*1.2*2m 16*1.5*2.5m
Power 15KW 20KW 25KW
Electronic control Controlled inverter + PLC entire control(may choose the use)
Machine Details

Technical parameters
parameters
φ25 φ30 φ35 φ45 φ50
Finished diameter(MM) 0.05∽1.0 0.28∽2.0 0.4∽3.0 0.6∽4.0 0.6∽5.0
Extrusion amount (KG) 6 20 25 60 60
Line speed(M/Min) 150 180 180 150 150
Screw rotation(rmp) 10-50 10-90 10-60 10-90 10-60
Total power(kw) 6.4 30 30 40 35
Host machine power(hp) 4 15 10 15 15
Traction power(hp) 2.2 3 2 3 3
Coiling machine power(hp) 1.5 2 2 3 3
Accumulate Power(hp) 2.2 1 1 2 2
Length to diameter ratio 25:1 25:1 25:1 25:1 25:1
Hopper capacity(KG) 10 12 12 25 25
Magnetic powder clutch(KG) 5 5 5 10 10
dryer electric heating(kw) 1.5 1.5 1.5 1.5 1.5
dryer air supply(w) 180 180 180 180 180
Traction wheel diameter(mm) 191.2 191.2 191.2 500 500
Accumulate wheel diameter(mm) 120 120 120 250 250
