Specifications
Brand Name :
Hongli
Model Number :
50
Certification :
CE
Place of Origin :
Dongguan
MOQ :
1 set
Price :
35,000$-55,000$
Payment Terms :
T/T, L/C
Supply Ability :
10 set per month
Delivery Time :
20-30 days
Packaging Details :
wooden packing
Name :
Wire Extruder Machine
screw :
70mm
capacity :
140kg/h
cable diameter :
1-10mm
cable size :
1.5,2.5,4,6
motor power :
22kw
motor brand :
siemens
inverter brand :
Yaskawa
length of machine :
21 meters
Description

Chinese Brand 1.5, 2.5 House Wire And Cable Jacket Sheath PE PVC Extruding Extruder Extrusion Making Machine

About us:
Our factory has been manufacturing extrusion lines for over 20 years ,we also produce copper buncher, cable twisting machine, copper drawing machine.Until now we have exported some production lines to Pakistan, iraq,Tunisia, Algerial, Egypt, India, Afghanistan,Nigeria, Sudan, we are still working on other country,

Main brands for our machine

- Motor: SIEMENS, DONGGUAN MOTOR,
- Inverter: YASKAWA, INOVANCE, SIEMENS,
- PLC: Siemens
- Touch Screen: Siemens
- Low-voltage electrical components: Schneider
- Bearings: NSK or SKF

Technical parameters sheet:

Machine model HL70 HL80 HL90 HL120 HL150 HL200
Cored wire spec. Φ1.5-12mm Φ2-20mm Φ3-25mm Φ10-50mm Φ40-80mm Φ60-150mm
Application Applicable to power wires, computer wire, data wire and high-frequency wire jacket and sheath extrusion
Extrusion material PVC, PE, LSZF, PE, PP, PU etc
Number of temperature control zones (main extruder + crosshead) 5+3 5+3 6+3 6+3 7+3 9+3
Driven power 40 HP 60HP 60HP 100HP 125HP 340HP
Max. Output 140KG/H 180KG/H 240KG/H 360KG/H 500KG/H 800KG/H
Max. Line speed 400m/min 300m/min 250m/min 180m/min 80m/min 80m/min

Extrusion Host

Applicable Material: PVCE, Plasticization degree of 100%.

Maximum Extrusion Capacity: 80kg/hr.

Finished wire diameter: 0.6—5mm

Mechanical Center Height: 1000mm

Ratio of Length and Diameter: 1:25

Compression Ratio: 1:26

Material of Screw: One Ø50mm, Rotation Rate of Screw: 0—120RPM,

screw with whole tooth nitrogen treatment of alloy steel and chrome-plated polished surface

Material of Screw Cylinder: 38CrMoA1A alloy steel, nitrogen treatment and precisely grinding. The surface hardness inside the screw cylinder is R2-3 degree higher than that of the front surface of the screw and the screw thread.

Gearbox: Imitation of Italian-type, hardened helical gear gearbox, material of cast steel, oil-bath lubrication, tooth-face high-efficiency quenching and adoption of Japanese NACHI bearing.

Electric Heating: total power 12kw,380V, with even three-phase separated flow.

Screw cylinder electric heating zone 3, the cast aluminum heating ring heating is affixed with cooling air duct.

Head electric heating zone 1, heating by cast aluminum heating ring.

Eye die electric heating zone 1, heating by the electro-thermal tablets.

Cooling: Screw cylinder zone 3, use 3 sets of cooling fans( 180W).

Control of Temperature: Use the PID automatic temperature control gauge made in Yangming, Taiwan, automatically set the control under 0-399℃ and use KTYP as the thermal-couple.

Machine head clamping: Using a ratchet quick wrench, chain drive double clamp.

Host Motor: 15HP. Jiangmen motor SINEE invertor
