Lightweight HT-SPC Polyimide Taped Wire 250V for Aerospace Communication Cable
Lightweight HT-SPC Polyimide Taped Wire 250V for Aerospace Communication Cable
Lightweight HT-SPC Polyimide Taped Wire 250V for Aerospace Communication Cable
Lightweight HT-SPC Polyimide Taped Wire 250V for Aerospace Communication Cable
Lightweight HT-SPC Polyimide Taped Wire 250V for Aerospace Communication Cable
Lightweight HT-SPC Polyimide Taped Wire 250V for Aerospace Communication Cable
Lightweight HT-SPC Polyimide Taped Wire 250V for Aerospace Communication Cable
Lightweight HT-SPC Polyimide Taped Wire 250V for Aerospace Communication Cable
Lightweight HT-SPC Polyimide Taped Wire 250V for Aerospace Communication Cable
Lightweight HT-SPC Polyimide Taped Wire 250V for Aerospace Communication Cable
Lightweight HT-SPC Polyimide Taped Wire 250V for Aerospace Communication Cable
Lightweight HT-SPC Polyimide Taped Wire 250V for Aerospace Communication Cable
Specifications
Model Number :
HT-SPC
Place of Origin :
Shanghai, China
Brand Name :
Bing Wire & Cable
MOQ :
1000 meters
Price :
$4.33-22.49 / meter
Certification :
CE/RoHS/ISO
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Supply Ability :
2000M 7work days
Delivery Time :
10-15 work days
Conductor Material :
electrolytic silver plated annealed copper or high strength silver plated copper alloy (SCA)
Insulation Material :
Wrapped and sealed PTFE/ Polyimide composited tape
Jacket :
PTFE tape top wrapped and sintered
Rated Voltage :
250V
Rated Temperature :
-90°~+200°C
Application :
Missile Systems/Extreme Engine Bay/Helicopter Avionics
Color :
Customized Color
Packing :
As requriement
Description
Product Description

HT-SPC polyimide taped wire is a premium Polyimide & PTFE wire engineered exclusively for aerospace applications where weight reduction is critical. As a professional Polyimide insulated aerospace cable, it features a thin 0.115mm polyimide/PTFE composite insulation and high-performance silver-plated copper conductor, delivering stable and reliable performance across an extreme temperature range of -90°C to +200°C. This Lightweight Heat Resistant Cable is the ideal wiring solution for aircraft, satellites, and other high-temperature, high-reliability environments.

  • Conductor: Annealed silver-plated electrolytic copper or high-strength silver-plated copper alloy.
  • Insulation: Fluororesin-coated PTFE or polyimide film tape wrapped and sintered.
  • Sheath: PTFE tape wrapped and sintered sheath, available in different colors (wire surface can be laser marked).
  • Insulation Detail: Fluororesin-coated PTFE or polyimide composite film insulation.
  • Operating Temperature: -90~+200℃.
  • Rated Voltage: AC 250V.
  • Insulation Thickness: 0.115 mm.
  • Standard Colors: Black, brown, red, orange, yellow, green, blue, purple, gray, white (custom colors available).
  • Multi-core Cables: Twisted pair, three-core stranded, four-core stranded, etc. (with/without sheath, with/without shielding optional).
Key Features
  • High-Conductivity Silver-Plated Copper: Available in both annealed electrolytic copper and high-strength copper alloy variants
  • Superior Corrosion Resistance: Silver plating ensures excellent oxidation resistance and maintains conductivity at high temperatures
  • Flame Retardant: Low flame propagation properties meeting stringent aerospace requirements
  • Arc Resistance: Superior resistance to electrical arcing
  • Chemical Resistance: Excellent resistance to aviation fuels, hydraulic fluids, and lubricants
  • Optimized for High-Frequency Applications: Enhanced skin effect performance for signal integrity
Applications
  • Commercial Aircraft: Internal wiring for avionics, flight control systems, and cabin electronics,where Lightweight Heat Resistant Cable is essential.
  • Missile Systems: Signal transmission and control systems ,supported by our reliable Polyimide insulated aerospace cable.
  • Medical Devices: Specialized equipment requiring biocompatible materials,Specialized equipment requiring biocompatible materials, using the stable structure of Polyimide & PTFE wire.
  • Instrumentation: Precision electronic equipment internal wiring,often implemented with our customized Multi-Core Cable.
Why Choose Our Polymide Taped Wire?

Our HT-SPC Polyimide Taped wire is designed for the harshest environments and extreme conditions. This silver plated copper wire may be used in commercial or mili tary aircraft where wire applications must adhere to strict restrictions and specifications. As a professional Electrolytic silver-plated copper cable, our high-performance ployimide taped wire meets the strictest requirements for small dimensions, high-temperature resistance, low weight, and low flame propagation, making it the top choice for Aerospace communication cable and mission-critical aerospace wiring.

Technical Specifications
PART NUMBER AWG CONSTRUCTION (mm) CONDUCTOR/ NOMNAL (mm) NOMNAL AREA (mm2) OMNAL RESISTANCE (Ω / 100m) INSULATED WIRE
NOMNAL (mm) APPROX. WEIGHT (g/m)
HT 3001 30 1/ 0.254 0.254 0.051 35 0.48 0.60
HT 3007 30 7/ 0.102 0.303 0.057 34 0.53 0.70
HT 2801 28 1/ 0.320 0.320 0.081 21 0.55 0.90
HT 2807 28 7/ 0.127 0.381 0.088 20 0.61 1.00
HT 2601 26 1/ 0.403 0.403 0.13 13 0.63 1.40
HT 2619 26 19/ 0.102 0.504 0.15 12 0.74 1.70
HT 2401 24 1/ 0.510 0.510 0.21 8.5 0.74 2.10
HT 2419 24 19/ 0.127 0.634 0.24 7.5 0.86 2.60
HT 2201 22 1/ 0.644 0.644 0.33 5.3 0.87 3.20
HT 2219 22 19/ 0.160 0.800 0.38 4.7 1.03 4.00
HT 2001 20 1/ 0.812 0.812 0.52 3.3 1.04 5.00
HT 2019 20 19/ 0.203 1.009 0.62 2.9 1.24 6.20
HT 1819 18 19/ 0.254 1.269 0.96 1.9 1.50 9.60
HT 1619 16 19/ 0.300 1.500 1.34 1.3 1.73 13.2
Product Detail

Lightweight HT-SPC Polyimide Taped Wire 250V for Aerospace Communication CableLightweight HT-SPC Polyimide Taped Wire 250V for Aerospace Communication Cable

Lightweight HT-SPC Polyimide Taped Wire 250V for Aerospace Communication CableLightweight HT-SPC Polyimide Taped Wire 250V for Aerospace Communication Cable

FAQ
1.Are you a manufacturer or a trading company?
A: We are a professional manufacturer of wires and cables, based in Shanghai, with extensive experience since 2005.
2.What’s your company MOQ?
A: To ensure the best cost and quality for different products, our MOQ varies, normally it's 2km. Please reach out to our sales team for specific and flexible options.
3.Can I get the samples?
A: Yes, we encourage you to verify our quality. Samples are available upon request. A nominal fee may apply, which is deductible from your future bulk order.
4.Does your company accept customization?
A: Yes, we provide both OEM and ODM services to meet your specific requirements.
5.How can I get the right price?
A: For a precise quotation tailored to your needs, please contact us with detailed specifications (e.g., type, length, color, packaging). We respond quickly.
6.What services can we provide?
A: We provide a seamless trading experience: Secure payment (T/T, PayPal), flexible trade terms (FOB Shanghai, EXW Shanghai, etc.), and cooperation with major logistics companies (DHL, FedEx, UPS, or your preferred agent) for door-to-door delivery.Other terms can be discussed based on your needs.
7.How long will the delivery take?
A: The general production lead time is 10-15 working days after order confirmation and deposit. Exact time depends on the order quantity and customization complexity.
8.How do you solve after sale service?
A: Our relationship doesn't end after a sale. We offer comprehensive after-sales support. If you encounter any issues, our team will provide a swift and effective solution to ensure your complete satisfaction.
