Seismic Resistance Prefabricated Steel Structure Mining Camp Buildings Custom
Seismic Resistance Prefabricated Steel Structure Mining Camp Buildings Custom
Seismic Resistance Prefabricated Steel Structure Mining Camp Buildings Custom
Seismic Resistance Prefabricated Steel Structure Mining Camp Buildings Custom
Seismic Resistance Prefabricated Steel Structure Mining Camp Buildings Custom
Seismic Resistance Prefabricated Steel Structure Mining Camp Buildings Custom
Specifications
Brand Name :
YAGO Industry
MOQ :
150m2
Delivery Time :
25-45days
Ordinary Bolts :
Galvanized bolts, grade 4.8
Roof Purlin :
Q235B, C Section steel, Galvanized 275g
Model Number :
YGCJ08
Place of Origin :
China
Payment Terms :
L/C,T/T
Supply Ability :
20000-30000units/month
Packaging Details :
By Pallet or As Request
Anchor Bolts :
Q235B anchor bolts
High-strength Bolts :
Grade 10.9 intensive bolts
Wall Purlin :
Q235B, C Section steel, Galvanized 275g
Certification :
ISO;CE
Main Structure :
H-Beam, Q355B section steel
Description
  • Product Name: China Prefabricated Mining Camp Buildings with Fabricated Steel Structure for Rapid Deployment
  • Product Brief: Large-span space load-bearing structure with light weight, wide span range, strong seismic resistance and elegant appearance. It is widely applied in stadiums, waiting halls, bulk material sheds, exhibition centers and other large open-space roof projects.
  • Product Specification:
    Main Steel Frame System
    Main Structure Main steel frame H-Beam, Q355B section steel with paint as per client request
    Roof purlin Roof purlins Q235B, C Section steel, Galvanized 275g
    Wall purlin Wall purlins Q235B, C Section steel, Galvanized 275g
    Intensive Bolt High-strength bolts Grade 10.9 intensive bolts
    Ordinary Bolt Ordinary bolts Galvanized bolts, grade 4.8
    Intensive Bolt Anchor bolts Q235B anchor bolts as per design
    Bracing System
    Cross brace Cross brace Φ20, steel Q235, With paint or Hot dip Galvanized as per client request
    Knee bracing Corner brace L50*4, steel Q235, With paint or Hot dip Galvanized as per client request
    Column bracing Intercolumnar brace Φ20, steel Q235, With paint or Hot dip Galvanized as per client request
    Tie bar Tie rod Φ89*3, steel Q235, With paint or Hot dip Galvanized as per client request
    Batter brace Stretcher Φ12round steel bar, steel Q235, With paint or Hot dip Galvanized as per client request
    Roofing System
    Roof panel Roofing panels Roof with Galvanized Color Steel Sheet Or Insulated Sandwich panel as per client request
    Edge cover Edge trims Galvanized Color Steel Sheet
    Fittings & accessories Accessories and auxiliary materials Nails,Screws Glue Bolts etc.
    Gutter Gutters Stainless Steel Gutter
    Rainspout pipes Downpipes Φ110 PVC rainspout pipes
    Unpowered ventilator Non-powered ventilators Φ500mm 304SS unpowered ventilator
    Wall System
    Exterior wall outside panel Exterior wall panels Wall with Galvanized Color Steel Sheet Or Insulated Sandwich panel as per client request
    Edge cover Edge trimmings Galvanized Color Steel Sheet
    Fittings & accessories Accessories and auxiliary materials Nails,Screws Glue Bolts etc.
  • Application Scenarios: Sports stadium, station waiting hall, exhibition center, large shopping mall, coal storage shed, bulk material closed shed, airport terminal roof system
  • FAQ

    Q1: What is the maximum span of steel grid structure?

    A1: Regular span covers 50m-80m, and customized design can break 100m.

    Q2: What is the main difference between grid and truss structure?

    A2: Space grid bears force in three-dimensional direction, more suitable for ultra-large span projects; steel truss mainly bears planar force.

    Q3: How is its wind and earthquake resistance performance?

    A3: It reaches 8-degree seismic resistance standard, and can resist grade 12 typhoon in coastal areas.

    Q4: What anti-corrosion method is used for coal shed grid structure?

    A4: Heavy-duty anti-corrosion paint and hot-dip galvanizing treatment are adopted to adapt to dusty and corrosive working environment.

    Q5: What are common matching roof panels?

    A5: Color steel sandwich panel, aluminum magnesium manganese plate and daylighting panel with daylighting belt are all optional.
