Lightweight Galvanized Prefab Steel Structure Hangar Workshop Frame
Lightweight Galvanized Prefab Steel Structure Hangar Workshop Frame
Lightweight Galvanized Prefab Steel Structure Hangar Workshop Frame
Lightweight Galvanized Prefab Steel Structure Hangar Workshop Frame
Lightweight Galvanized Prefab Steel Structure Hangar Workshop Frame
Lightweight Galvanized Prefab Steel Structure Hangar Workshop Frame
Specifications
Main Structure: :
H-Beam, Q355B Section Steel
Wall Purlin :
Q235B C-Section steel, Galvanized 275g
Main Structure :
H-Beam, Q355B Section Steel
MOQ :
150㎡
High-strength Bolts :
Grade 10.9 intensive bolts
Payment Terms :
L/C,T/T
Packaging Details :
By Pallet or As Request
Brand Name :
YAGO Industry
Model Number :
YGKL29
Certification :
ISO;CE
Place of Origin :
CHINA
Supply Ability :
20000-30000 ㎡
Cross Brace :
Φ20, steel Q235
Roof Purlin :
Q235B C-Section steel, Galvanized 275g
Delivery Time :
24-45Days
Unpowered Ventilator :
Φ500mm 304SS
Description
Fabricated Steel Structure Hangar and Workshop Export to Global
Product Overview
Our fabricated steel structure hangars and workshops are engineered for global export with premium components and international compliance standards.
  • Heavy-Duty International Core: Built around structural Q355B H-beam steel main framework with professional painted finishes engineered to pass global structural validation codes
  • Marine-Grade Secondary Purlins: Roof and wall structural layouts incorporate Q235B C-Section steel purlins with 275g hot-dip galvanized layer for maritime transit protection
  • All-Climate Tension System: Integrates high-tensile Φ20 steel cross bracings, rigid L50×4 corner braces, Φ20 intercolumn bars, Φ89×3 heavy tie rods, and Φ12 steel stretchers
  • Global Procurement Fasteners: All building grid joints secured via Grade 10.9 high-strength intensive bolts, Grade 4.8 galvanized ordinary hardware, and customizable Q235B foundation anchor bolts
  • Premium Ocean-Ready Envelope: Configured with heavy Galvalume color plates or high-efficiency sandwich panels, paired with stainless steel gutters, Φ110 PVC downpipes, and Φ600mm 304SS unpowered roof ventilators
Product Advantages
  • Engineered for Global Compliance: Designed to accommodate varied international load requirements including extreme wind velocities, heavy localized snow loads, and severe seismic zones
  • Sea-Freight Anti-Corrosion Defense: Thick 275g zinc layer on secondary steel prevents oxidation and salt-air rusting during intercontinental shipping and port storage
  • Massive Clear-Span Capabilities: High-tensile Q355B H-beam frames provide column-free interior expanses ideal for large aircraft or continuous industrial machinery lines
  • Rapid Interlocking Bolt Assembly: Pre-engineered, factory-matched connection holes and Grade 10.9 hardware eliminate need for complicated on-site field welding
  • Zero-Energy Thermal Balancing: Integrated Φ600mm 304 stainless steel unpowered ventilators maintain optimal interior air quality by extracting hot air, fumes, and moisture without electrical power
Application Scenarios
  • International Aviation Hangars: Clear-span, high-clearance buildings for parking, maintaining, and servicing commercial aircraft, helicopters, or private corporate jets
  • Cross-Border Manufacturing Factories: Large-scale industrial processing plants with integrated runway brackets to support multi-ton overhead traveling cranes
  • Global Port Logistic Workshops: Marine-adjacent repair facilities utilizing high-level 275g galvanized grids to combat dense saltwater air
  • Intercontinental Distribution Warehouses: Expansive multi-span logistics hubs engineered for high-density automated racking and rapid forklift cross-docking operations
  • Remote Mining Machinery Enclosures: Heavy-duty maintenance depots exported to rugged international territories for large earthmovers and industrial drilling equipment
Frequently Asked Questions
How do you guarantee the building design satisfies our specific country's local building codes?
Before fabrication, our engineering team utilizes technical parameters of the Q355B H-beam framework and tension bracing matrices to calculate specific wind load, snow load, and seismic ratings. We customize structural details to align directly with your country's architectural standards.
What steps are taken to protect the prefabricated steel components from rusting during sea transit?
All secondary framing components, such as C-section roof and wall purlins, are upgraded to Q235B steel featuring a thick 275g galvanized layer. The primary Q355B H-beam columns are coated with heavy-duty industrial primer and protective paint, and the entire kit is securely bundled for ocean container shipping.
Can the main steel columns handle the heavy loading of an overhead bridge crane for a workshop layout?
Yes. Because structural columns and roof rafters are built using rigid, high-tensile Q355B H-beams rather than light-gauge metal, they are fully capable of supporting heavy crane operations. We can pre-fabricate custom crane runway beams and column brackets based on your load specifications.
Is the roofing system optimized to handle high temperatures and moisture in tropical export zones?
Absolutely. For tropical climates, we recommend upgrading the Galvalume cladding to our premium insulated sandwich panels. The roof system also incorporates deep stainless steel gutters for heavy downpours and Φ600mm 304SS unpowered ventilators to exhaust heat and humidity naturally.
What hardware is supplied in the export package to secure the building to our concrete pad?
The export kit includes a complete industrial fastening layout featuring project-specific Q235B foundation anchor bolts to lock main columns into your concrete foundation, along with Grade 10.9 high-strength intensive bolts and Grade 4.8 ordinary galvanized hardware to secure all remaining joints.
Technical Specifications
Main Steel Frame System
Component Description Specifications
Main Structure Main steel frame H-Beam, Q355B section steel with paint as per client request
Roof purlin Roof purlins Q235B, C Section steel, Galvanized 275g
Wall purlin Wall purlins Q235B, C Section steel, Galvanized 275g
Intensive Bolt High-strength bolts Grade 10.9 intensive bolts
Ordinary Bolt Ordinary bolts Galvanized bolts, grade 4.8
Intensive Bolt Anchor bolts Q235B anchor bolts as per design
Bracing System
Component Description Specifications
Cross brace Cross brace Φ20, steel Q235, With paint or Hot dip Galvanized as per client request
Knee bracing Corner brace L50×4, steel Q235, With paint or Hot dip Galvanized as per client request
Column bracing Intercolumnar brace Φ20, steel Q235, With paint or Hot dip Galvanized as per client request
Tie bar Tie rod Φ89×3, steel Q235, With paint or Hot dip Galvanized as per client request
Batter brace Stretcher Φ12 round steel bar, steel Q235, With paint or Hot dip Galvanized as per client request
Roofing System
Component Description Specifications
Roof panel Roofing panels Roof with Galvanized Color Steel Sheet Or Insulated Sandwich panel as per client request
Edge cover Edge trims Galvanized Color Steel Sheet
Fittings & accessories Accessories and auxiliary materials Nails, Screws, Glue, Bolts etc.
Gutter Gutters Stainless Steel Gutter
Rainspout pipes Downpipes Φ110 PVC rainspout pipes
Unpowered ventilator Non-powered ventilators Φ500mm 304SS unpowered ventilator
Wall System
Component Description Specifications
Exterior wall outside panel Exterior wall panels Wall with Galvanized Color Steel Sheet Or Insulated Sandwich panel as per client request
Edge cover Edge trimmings Galvanized Color Steel Sheet
Fittings & accessories Accessories and auxiliary materials Nails, Screws, Glue, Bolts etc.
