Specifications
Roof structure :
Q235 galvanized Steel profile
Place of Origin :
China
Wall panel :
50mm/75mm fireproof Mineral Rockwool Sandwich panel
MOQ :
6units
Payment Terms :
L/C,T/T
Certification :
ISO;CE
Air leakage rate :
<0.1% per hour
Model Number :
YGCJ19
Packaging Details :
By Pallet or As Request
Light :
LED light, 24W
Insulation :
Fiber glass with aluminum foil
Supply Ability :
1500-2000units/month
Delivery Time :
25-45days
Dimensions :
6.06*2.435*2.89m
Brand Name :
YAGO Industry
Description
Container Modular House Units for Temporary Housing, Remote Worksites, and Rapid Deployment Projects Globally
Product Introduction

This YAGO medical isolation container house is a professional temporary isolation facility with high airtightness, excellent disinfection performance, complete medical facilities and quick setup. It provides safe and reliable isolation and medical observation space for epidemic prevention, emergency medical treatment, remote medical service and disaster relief.

Product Description

This medical isolation container house is designed in strict accordance with medical isolation standards. Adopting high‑airtightness modular structure, it effectively prevents the spread of viruses and bacteria. The wall, roof and floor use non‑toxic, tasteless and easy‑to‑disinfect materials, supporting repeated disinfection with various disinfectants. The 75mm PU fireproof insulation panels ensure comfortable indoor environment. It is equipped with professional negative pressure ventilation system, HEPA filter, UV disinfection lamp, oxygen supply system and medical facilities, meeting medical isolation requirements. The interior is divided into isolation area, buffer area and medical operation area, realizing rational functional layout. Factory prefabrication and quick assembly enable it to be put into use within 24 hours, effectively responding to public health emergencies. It supports multi‑unit combination and rapid expansion into temporary isolation hospital.

Application Scenarios
  • Epidemic prevention and control temporary isolation point
  • Close contact medical observation station
  • Emergency medical shelter and mobile clinic
  • Disaster relief medical station and first aid center
  • Remote area temporary medical and health room
  • Public health emergency command center
Specifications
Fpatpack container SPECIFICATION SHEET
Project name: Flatpack Container 6.06*2.435*2.89m
A Item Specification
Steel Frame System System
1 Roof structure Main roof frame: Q235 galvanized Steel profile, with Automatic Powder Coated paint Roof purlin: C Section Steel, galvanized. Q235B steel
2 Floor structure Main floor frame: Q235 galvanized Steel profile,with Automatic Powder Coated paint Floor purlin:C Section Steel, galvanized. Q235B steel
3 Corner pillar Q235 galvanized Steel profile, Galvanized with Automatic Powder Coated paint
Container roof System
1 Roof covering Galvanized Powder Coated color painting steel Sheet.
2 Insulation Fiber glass with aluminum foil
3 Ceiling board Galvanized Powder Coated color painting steel Sheet.
Container floor System
1 PVC flooring Vinly floor leather with glue
2 Floor board 18mm fiber cement board
ContainerWall System
1 Wall panel 50mm /75mm fireproof Mineral Rockwool Sandwich panel
2 Door Insulated Steel Door
3 Window PVC sliding window, double glass, with fly screen
Container Electrical System
1 Power distribution cabinet Circuits with air-break switch, leakage protector,
2 Light LED light, 24W
3 AC Socket 16A universal, with socket box
4 Common Socket 10A, Universal type, with socket box
5 Switch 10A , with switch box
Plumbing system(Optional as per drawing)
1 washbasin including the accessory
2 Closetool including the accessory
3 shower shower base, shower head, water mixture
4 Exhaust Fan 6 Inch
5 water pipe input and output water pipe
Stair case and Corridor. (Optional as per drawing)
1 Stair Case and Corridor Fabricated with C channel steel, square tube, Round Steel, And checkered Steel Plate
Additional Traingle Roof on Top of Each Block. (Optional as per drawing)
1 Roof Structure Fabricated with C section steel, Galvanized Q235 Steel.
2 Roof Covering Corrugated Galvanized Powder Coated Roof Tile
Advantages
  • Professional isolation: High airtightness, negative pressure system, effectively blocking virus spread
  • Easy disinfection: Antibacterial and disinfection‑resistant materials, repeated disinfection
  • Complete medical facilities: Equipped with professional medical equipment, meeting isolation needs
  • Quick deployment: Factory prefabrication, 24‑hour rapid assembly and use
  • Flexible expansion: Multi‑unit combination, rapid expansion into temporary isolation hospital
  • Safe and reliable: Fireproof, waterproof, antibacterial, complying with medical standards
FAQ

Q: What is the airtightness level?

A: Meets national medical isolation airtightness standard, air leakage rate <0.1% per hour.

Q: Can it be repeatedly disinfected?

A: Yes, surface materials resist disinfection, suitable for 84 disinfectant, alcohol, etc.

Q: Is the negative pressure system adjustable?

A: Yes, negative pressure value can be adjusted from ‑10Pa to ‑30Pa according to needs.

Q: How many people can one unit accommodate?

A: Standard unit accommodates 1–2 isolated persons, customizable for more people.

Q: Can it be used for long time?

A: Yes, high‑quality materials ensure long‑term use after regular maintenance.
