20ft Foldable Prefabricated Container Building Solutions For Modular Housing Temporary Camp
20ft Foldable Prefabricated Container Building Solutions For Modular Housing Temporary Camp
20ft Foldable Prefabricated Container Building Solutions For Modular Housing Temporary Camp
20ft Foldable Prefabricated Container Building Solutions For Modular Housing Temporary Camp
20ft Foldable Prefabricated Container Building Solutions For Modular Housing Temporary Camp
20ft Foldable Prefabricated Container Building Solutions For Modular Housing Temporary Camp
Specifications
Expanded dimensions :
6.06*2.435*2.89m
Brand Name :
YAGO Industry
Model Number :
YGCJ20
Floor board :
18mm fiber cement board
Light power :
LED light, 24W
Packaging Details :
By Pallet or As Request
Expansion time :
5 minutes (automatic hydraulic)
Roof insulation :
Fiber glass with aluminum foil
MOQ :
6units
Payment Terms :
L/C,T/T
Wall panel thickness :
50mm/75mm fireproof Mineral Rockwool Sandwich panel
Certification :
ISO;CE
Place of Origin :
China
Delivery Time :
25-45days
Supply Ability :
1500-2000units/month
Description
China Prefabricated Building Solutions for Modular Housing, Temporary Camps, and Industrial Construction Projects
Product Introduction

This YAGO expandable wing container house is a space‑expandable integrated modular building with automatic or manual expanding structure. It provides spacious, comfortable and fully equipped temporary living and office space for high‑end camps, mobile villas, small teams and family outdoor accommodation.

Product Description

This expandable wing container house adopts double‑side hydraulic expanding wings, which can expand the internal space by 2 times in 5 minutes. The main body uses heavy‑duty steel frame and 75mm PU fireproof sandwich panels with excellent thermal insulation. Interior is fully decorated with bedroom, living room, kitchen and bathroom integrated. All electrical, plumbing and lighting systems are pre‑installed. It can be transported as a standard container and quickly put into use after expansion, creating a comfortable mobile house with large space.

Application Scenarios
  • High‑end mobile villa & family holiday house
  • Scenic spot luxury homestay
  • Small team field camp & office
  • Mobile business reception room
  • Emergency command & mobile lounge
Specifications
Fpatpack container SPECIFICATION SHEET
Project name: Flatpack Container 6.06*2.435*2.89m
AItemSpecification
Steel Frame System System
1 Roof structureMain roof frame: Q235 galvanized Steel profile, with Automatic Powder Coated paint Roof purlin: C Section Steel, galvanized. Q235B steel
2 Floor structureMain floor frame: Q235 galvanized Steel profile,with Automatic Powder Coated paint Floor purlin:C Section Steel, galvanized. Q235B steel
3 Corner pillar Q235 galvanized Steel profile, Galvanized with Automatic Powder Coated paint
Container roof System
1 Roof covering Galvanized Powder Coated color painting steel Sheet.
2 Insulation Fiber glass with aluminum foil
3 Ceiling board Galvanized Powder Coated color painting steel Sheet.
Container floor System
1 PVC flooring Vinly floor leather with glue
2 Floor board18mm fiber cement board
ContainerWall System
1 Wall panel50mm /75mm fireproof Mineral Rockwool Sandwich panel
2 DoorInsulated Steel Door
3 WindowPVC sliding window, double glass, with fly screen
Container Electrical System
1 Power distribution cabinetCircuits with air-break switch, leakage protector,
2 LightLED light, 24W
3 AC Socket16A universal, with socket box
4 Common Socket10A, Universal type, with socket box
5 Switch10A , with switch box
Plumbing system(Optional as per drawing)
1 washbasinincluding the accessory
2 Closetoolincluding the accessory
3 showershower base, shower head, water mixture
4 Exhaust Fan 6 Inch
5 water pipeinput and output water pipe
Stair case and Corridor. (Optional as per drawing)
1 Stair Case and CorridorFabricated with C channel steel, square tube, Round Steel, And checkered Steel Plate
Additional Traingle Roof on Top of Each Block. (Optional as per drawing)
1 Roof StructureFabricated with C section steel, Galvanized Q235 Steel.
2 Roof CoveringCorrugated Galvanized Powder Coated Roof Tile
Advantages
  • 5‑minute fast expansion, space doubled
  • Fully integrated interior, ready to use
  • Excellent thermal & sound insulation
  • Luxury living experience in mobile space
  • Strong mobility & reusable
FAQ
Q: How long does expansion take?
A: Automatic hydraulic type: ~5 minutes; manual type: ~15 minutes.
Q: Can it be transported by container ship?
A: Yes, folded size is standard 20ft container.
Q: Is it suitable for long‑term residence?
A: Yes, same comfort as traditional apartment.
Q: Can we customize interior layout?
A: Yes, layout, decoration and facilities are customizable.
Q: What is the service life?
A: 15–20 years under normal maintenance.
