M12 Stainless Steel Inductive Proximity Switch Sensor 4-8mm Range Detection For Iron Metal
M12 Stainless Steel Inductive Proximity Switch Sensor 4-8mm Range Detection For Iron Metal
M12 Stainless Steel Inductive Proximity Switch Sensor 4-8mm Range Detection For Iron Metal
M12 Stainless Steel Inductive Proximity Switch Sensor 4-8mm Range Detection For Iron Metal
M12 Stainless Steel Inductive Proximity Switch Sensor 4-8mm Range Detection For Iron Metal
M12 Stainless Steel Inductive Proximity Switch Sensor 4-8mm Range Detection For Iron Metal
Specifications
Brand Name :
BOJKE
Model Number :
SR12 series
Certification :
CE
Place of Origin :
Dongguan China
MOQ :
1pcs
Price :
$3.8~4.6
Payment Terms :
T/T
Supply Ability :
150k
Delivery Time :
5~8 work days
Packaging Details :
PP bag with carton box;
Power supply :
DC 10~30V
Wires :
3 wires
Type :
Flush and Non-flush
Diameter :
M12
Name :
Inductive Proximity Switch Sensor
Description

M12 Stainless Steel Inductive Proximity Switch Sensor 4~8mm Range Detection For Iron Metal

Product Name Inductive proximity sensor
Material Sensing surface:PBT Housing:stainless steel
Function Detection metal presence

M12 Stainless Steel Inductive Proximity Switch Sensor 4-8mm Range Detection For Iron Metal

Adopt non-contact position detection, no abrasion to the target, higher reliability; clearly visible indicator, easier to judge the working status; Φ3 to M30 dimensions, body length from ultra-short, short to long, extended long; Cable and connector connections are available; Adopt special IC for more stable performance; short circuit protection and polarity protection; capable of all kinds of limit and counting control, suitable for various industrial occasions such as high temperature, high pressure and wide voltage.

Model # NPN NO SR08-02NOF SR08-02NON SR08-04NON
NPN NC SR08-02NCF SR08-02NCN SR08-04NCN
Product Picture
Mounting Type Flush Non flush
Size (mm) M8x42 M8x46
Sensing Range (mm) 2.0 2.0 4.0
Repeat Accuracy <3%(Sr)
Hysteresis (Tolerance Distance) <15%(Sr)
Response Frequency(Hz) 1000 800
Operation Voltage DC 10~30V ±10%
Residue Voltage (Voltage Drop) <1.5V
Max Load Current 100mA
Consumption (no-load) Current <10mA
Leakage Current <0.01mA
Ambient Temperature Operation:-25℃~75℃；Storage:-40℃~85℃,no freezing
Ambient Humidity 35%~85% RH, no condensation
Protection Circuit Polarity reversal protection/surge protection/short circuit protection
Protection Level IP67
Material Sensing surface:POM；Housing material:stainless steel (SUS303)
Withstand Voltage AC 1000V, 50/60Hz, 1分钟 AC 1000V, 50/60Hz, 1 minute
Vibration Resistance 10～55Hz,Dual amplitude 1.5mm, 30 min each in X/Y/Z direction
Impact Resistance 300m/S2, X,Y,Z direction each 3 times
Insulation impedance Above 50MΩ(DC 500VMegger)
Indicator Detection object: Yellow
Connection 2 meters 3 core standard cable,can be customize
