M18 Inductive Proximity Sensor Stainless Steel Switch Proximity Sensor 5-12mm Sensing Range For Iron
M18 Inductive Proximity Sensor Stainless Steel Switch Proximity Sensor 5-12mm Sensing Range For Iron
M18 Inductive Proximity Sensor Stainless Steel Switch Proximity Sensor 5-12mm Sensing Range For Iron
M18 Inductive Proximity Sensor Stainless Steel Switch Proximity Sensor 5-12mm Sensing Range For Iron
M18 Inductive Proximity Sensor Stainless Steel Switch Proximity Sensor 5-12mm Sensing Range For Iron
M18 Inductive Proximity Sensor Stainless Steel Switch Proximity Sensor 5-12mm Sensing Range For Iron
M18 Inductive Proximity Sensor Stainless Steel Switch Proximity Sensor 5-12mm Sensing Range For Iron
M18 Inductive Proximity Sensor Stainless Steel Switch Proximity Sensor 5-12mm Sensing Range For Iron
Specifications
Place of Origin :
Guangdong, China
Brand Name :
BOJKE
MOQ :
2
Price :
$9.48
Certification :
CE
Payment Terms :
T/T
Supply Ability :
150k
Delivery Time :
5~8 work days
Packaging Details :
PP bag with carton box;
Product name :
M18 switch proximity sensor
Mounting Type :
Non-flush & fulsh
Type :
inductive sensor proximity switch
Usage :
iron and aluminum Detection
Output :
NPN Normally closed/Normally open
Diameter :
M18
Housing material :
stainless steel
Sensing distance :
5mm ~ 12mm
Supply voltage :
10~30 V DC
Standard cable :
2 meter 3 core
Description
Product Description
Product Name
Proximity sensors
Material
Sensing surface: PBT Housing Material: nickle copper alloy
Function
sensing aluminum, iron, and other metal
Package
pp bag with carton box
M18 Inductive Proximity Sensor Stainless Steel Switch Proximity Sensor 5-12mm Sensing Range For Iron
Type M18
Model No NPN NO SR18-05NOF SR18-08NOF SR18-08NON SR18-12NON
NPN NC SR18-05NCF SR18-08NCF SR18-08NCN SR18-12NCN
Mounting Type Flush Non flush
Size(mm) M18x44 M18x52
Sensing Range(mm) 5.0 8.0 8.0 12.0
Repeat Accuracy <3%(Sr)
Hysteresis <15%(Sr)
Response Frequency 1000 500 150
Operation Voltage DC 10~30V ±10%
Residue Voltage <2.0V
Max Load Current 200mA
Consumption (without-load) Current <10mA
Leakage Current <0.01mA
Ambient Temperature Operation temperature:-25℃~75℃；Storage temperature:-40℃~85℃,no freezing
Ambient Humidity 35%~85% RH, no condensation
Protection Circuit Polarity reversal protection/surge protection/short circuit protection
Protection Level IP67
Material Sensing surface: PBT；Housing material:Nickel-copper alloy
Withstand Voltage AC 1000V, 50/60Hz, 1 minute
Vibration Resistance 10～55Hz,Dual amplitude 1.5mm, 2 hours each in X/Y/Z directions
Impact Resistance 500m/S2, X,Y,Z direction each 10 times
Insulation impedance Above 50MΩ(DC 500VMegger)
Indicator when detection object: LED yellow
Connection 2 meters 3 core standard cable,can be customize
