Specifications
Brand Name :
LVJOE
Model Number :
1300FM
Certification :
ISO CE
Place of Origin :
Hebei，China(Mainland)
MOQ :
1 line
Price :
US $20000-200000
Payment Terms :
L/C,T/T
Supply Ability :
10 lines per Year
Delivery Time :
2 Months
Packaging Details :
Standard packing
Product Name :
High Quality Automatic Pvc Lamination Machine Gypsum Board Veneer Laminate Machine
Keyword :
PVC Film Laminating Machine for MDF Panel Boards
Finished board type :
PVC laminated gypsum board
Effective laminating :
1300mm
electric control :
PLC system
Production Capacity :
2-6 million Sq.m/year
Speed :
2-15m/min (adjustable)
After-sales Service :
Engineers available to service
Warranty :
1 year
Glue type :
Water Glue for PVC film
Description
Energy Saving PVC Laminated Plasterboard Machine Production Line

This advanced automatic PVC lamination machine is designed for laminating fiber glass, paper, PVC film, and aluminum foil onto gypsum boards. The finished products are ideal for ceiling tiles and partition wall panels, delivering professional-grade results with exceptional efficiency.
Product Specifications
Finished board type PVC laminated gypsum board
Effective laminating width 1300mm
Electric control system PLC system
Production capacity 2-6 million Sq.m/year
Operating speed 2-15m/min (adjustable)
Glue type Water Glue for PVC film
Warranty 1 year
After-sales service Engineers available to service
Automatic Gypsum Board Feeding Machine
The cylinder pushes gypsum boards from the stack lift platform to the conveyor roll, preparing them for PVC and aluminum film lamination.
Maximum load-bearing capacity 3000kg
Stroke 1500mm
Minimum height 620mm
Maximum height 2000mm
Platform size 1200×2400mm
Automatic Cutting Machine
Features two cutting systems: vertical/longitudinal cutting and horizontal cutting, equipped with a dust collector system. Cuts 1.2×2.4m large boards into 603×603mm/595×595mm small boards.
Cutting speed 15m/min
Cutting knife configuration Vertical/longitudinal: 3 blades; Horizontal: 5 blades
Overall power 17.15KW
Technical Specifications
  • Sheet thickness range: 5-30mm
  • Speed adjustment: Frequency conversion synchronous speed regulating
  • Annual capacity: 2-6 million Sq.m
  • Compatible film materials: PVC film, aluminum foils, decorative materials
  • Board sheet materials: PVC baseboard, gypsum board, wood board, sectional board, PVC foam board
  • Stacking mode: 10 layers (4 packages/layer)
  • Cutting configuration: Lengthways: 3 blades, Horizontal: 5 blades
  • Overall dimensions: Length: 56000mm, Width: 9200mm
  • Lamination modes: Double side (laminate front and back at once) or Single side
