Stainless Steel High Temperature Centrifugal Fan Blower 1 Year Warranty
Stainless Steel High Temperature Centrifugal Fan Blower 1 Year Warranty
Stainless Steel High Temperature Centrifugal Fan Blower 1 Year Warranty
Stainless Steel High Temperature Centrifugal Fan Blower 1 Year Warranty
Stainless Steel High Temperature Centrifugal Fan Blower 1 Year Warranty
Stainless Steel High Temperature Centrifugal Fan Blower 1 Year Warranty
Stainless Steel High Temperature Centrifugal Fan Blower 1 Year Warranty
Stainless Steel High Temperature Centrifugal Fan Blower 1 Year Warranty
Specifications
Brand Name :
XIANRUN BLOWER
Model Number :
ZR- HT Model
Certification :
CE, ISO 9001
Place of Origin :
XINXIANG
MOQ :
1
Price :
50-50000
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
10000
Delivery Time :
5-45DAYS
Packaging Details :
WOODEN PACKING
Blade material :
Stainless Steel,Cast Iron,Steel plate,Q345 (16Mn) manganese steel
Power :
5 - 350KW
Color :
Customer's Requirement
Air volume :
800 - 90000m3 / h
Voltage :
220V/380V/440V/480V/660V
Material :
Steel,316L,Carbon Steel /Stainless Steel,Q235
Type :
Centrifugal Fan,Multi-wings Industrial Centrifugal Exhaust Blower Fan,centrifugal blower,high pressure blower
Warranty :
1 Year
Applications :
Cooling systems
Name :
Industrial Axial Flow Fan
Description

High temperature centrifugal fan centrifugal blower stainless steel blower special fan brushless cooling fan

The high temperature fan is mainly composed of impeller, casing, air inlet, motor, connector, cooling blade, etc.

1. The impeller adopts multi-wing single inlet centrifugal impeller, made of high quality galvanized sheet or cold rolled steel plate, and the blades are designed according to the aerodynamic principle. The impeller consists of 10 backsloping airfow-type blades, curved-type front disks, and flat rear disks. The material is made of high-quality steel plate with high strength and good durability, and is corrected by strict dynamic and static balance, with good air performance, high efficiency and smooth operation.

2. The air inlet adopts the form of convergent streamline vortex reduction, the airflow loss is small, and the high temperature fan has high working efficiency.

3. The high temperature fan shell and motor are installed and connected with metal casting, the motor shaft head is installed with cooling blades, and the outer wall of the metal casting is set up with inlet and outlet water pipes to cool the metal casting and shaft head to ensure the normal operation of the motor under high temperature.

Stainless Steel High Temperature Centrifugal Fan Blower 1 Year Warranty

Stainless Steel High Temperature Centrifugal Fan Blower 1 Year Warranty

Stainless Steel High Temperature Centrifugal Fan Blower 1 Year Warranty

Key Features

  • Impeller diameter: 90~3500mm
  • Speed of mainshaft: 560~2900 rpm
  • Pressure range: 3000~25425 Pa
  • Flow range: 1297~83305 m3/h
  • Air Temperature: 20~1000 Celsius degree

  • Material: Cast Iron, Carbon Steel, Stainless Steel.

  • Efficiency: 80%-90%

Applications

  • Cement
  • Industrial boiler
  • Power generation
  • Chemical processing
  • Combustion-support
  • Cooling systems
  • Corrosive gas
  • Dryer
  • Dust collection
  • Forced draft
  • Fume exhaust
  • General ventilation
  • Incineration
  • Induced draft

Please advise us the USAGE and following Parameter.Our engineering Dept will recommend the most suitable product for you.

Air volume/air flow m3/h
Total pressure or static pressure Pa
Medium temperature °c
Voltage V
Frequency Hz
Altitude of operation place m
