Stainless Steel EC Centrifugal Inline Blower 85-95% Efficiency
Stainless Steel EC Centrifugal Inline Blower 85-95% Efficiency
Stainless Steel EC Centrifugal Inline Blower 85-95% Efficiency
Stainless Steel EC Centrifugal Inline Blower 85-95% Efficiency
Stainless Steel EC Centrifugal Inline Blower 85-95% Efficiency
Stainless Steel EC Centrifugal Inline Blower 85-95% Efficiency
Stainless Steel EC Centrifugal Inline Blower 85-95% Efficiency
Stainless Steel EC Centrifugal Inline Blower 85-95% Efficiency
Specifications
Brand Name :
XIANRUN BLOWER
Model Number :
XR-HT SERIES
Certification :
CE, ISO 9001
Place of Origin :
XINXIANG
MOQ :
1
Price :
50-50000
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
10000
Delivery Time :
5-45DAYS
Packaging Details :
WOODEN PACKING
Material :
Stainless Steel( 3014. 310. 316)
Blade material :
Stainless Steel,Cast Iron,Plastic,Steel Plate,Galvanized sheet
Mounting :
Free Standing,Duct Fan,Wall Fan,Other,screw
Application :
Industrial Boiler
Applications :
Cooling systems
Name :
Industrial Axial Flow Fan
Description

High Temperature Fan Ec Centrifugal Fan With Low Noise Fan Half Couplings In-Line Centrifugal Fan Industrial Boiler

The alignment accuracy of the coupling of high temperature centrifugal fan is very high, and the coaxiality of its normal operating state must be ensured within 0.05mm. With the above two methods of alignment, due to the coupling itself processing error and surface dirt, the actual coaxiality value will often exceed the normal range of several times or even more than ten times, so that the fan will produce serious vibration. Method :

1. It is generally used for rough finding of coupling or occasions with low requirements, and should not be used for high temperature fan alignment;

2. Method does not eliminate the influence of shape error, still can not meet the operation requirements of high temperature fan.
Correct practice:


Temporarily connect the two half couplings with 2 ~ 3 bolts, let them rotate synchronously, measure their radial and axial runout values with 3 (fast alignment method) or 2 dial gauges, and finally adjust to the required range.

In order to ensure that the fan, hydraulic coupling and motor center line theoretically form a straight line during the normal operation of the hot state, the hydraulic coupling center line is deliberately set to be a lower expansion difference δthan the motor and fan center line during the cold state alignment. Generally, δis set to be 0.1-0.2mm.

Stainless Steel EC Centrifugal Inline Blower 85-95% Efficiency

Key Features

Impellr 540-3211 mm
Flow range 1850-840000m 3/h
Pressure Range 1999-19786 Pa
Efficiency 85-95%
Temperature 20-1000 ℃
Material: Stainless Steel( 3014. 310. 316)

Applications

  • Industrial boiler
  • Power generation
  • Chemical processing
  • Combustion-support
  • Cooling systems
  • Corrosive gas
  • Dryer
  • Dust collection
  • Forced draft
