High temperature centrifugal blower fan working current stainless steel blower industrial centrifugal fan

High temperature centrifugal blower fan working more than 200 degrees, we recommend the use of high temperature stainless steel centrifugal fan, can achieve effective high temperature resistance effect. According to the different use environment, the selection of stainless steel material and process will also change slightly. Today Xiaobian has made the following summary of the characteristics of high-temperature stainless steel centrifugal fans.

Five characteristics of high temperature stainless steel centrifugal fan:
1, high temperature stainless steel centrifugal fan motor adopts special high temperature motor, high temperature centrifugal fan fluid part adopts temperature resistance material, cooling structure performance is reliable;
2, high temperature stainless steel centrifugal fan is mainly composed of impeller, casing, air inlet, motor, connector, cooling blade and other parts;
3, most of the impeller is made of multi-wing single inlet centrifugal impeller or tilting high-pressure centrifugal impeller. The material is made of high-quality stainless steel plate with high strength and good durability. The blades are designed according to the aerodynamic principle, and are strictly calibrated for dynamic and static balance.
4. The air inlet adopts the form of convergent streamline vortex reduction, the airflow loss is small, the high temperature resistant centrifugal fan has high working efficiency, good air performance, high efficiency, and stable operation.
5. Stainless steel high-temperature resistant centrifugal fan shell and motor are installed and connected with metal casting, the motor shaft head is installed with cooling blades, and the outer wall of the metal casting is opened with inlet and outlet pipe interface to cool the metal casting and shaft head to ensure the normal operation of the motor under high temperature.

Key Features

• Impeller diameter: 70~3500 mm
• Speed of mainshaft: 560~2900 rpm
• Pressure range: 1000~25425 Pa
• Flow range: 3297~733050 m3/h
• Air Temperature: 20~1000 Celsius degree

• Material: Stainless Steel,304.310.316.

• Efficiency: 70%-90%
