3000L 9-Layer Large Eco-Friendly Water Tank Blow Molding Machine with Purification Cooling System
3000L 9-Layer Large Eco-Friendly Water Tank Blow Molding Machine with Purification Cooling System
3000L 9-Layer Large Eco-Friendly Water Tank Blow Molding Machine with Purification Cooling System
3000L 9-Layer Large Eco-Friendly Water Tank Blow Molding Machine with Purification Cooling System
3000L 9-Layer Large Eco-Friendly Water Tank Blow Molding Machine with Purification Cooling System
3000L 9-Layer Large Eco-Friendly Water Tank Blow Molding Machine with Purification Cooling System
3000L 9-Layer Large Eco-Friendly Water Tank Blow Molding Machine with Purification Cooling System
3000L 9-Layer Large Eco-Friendly Water Tank Blow Molding Machine with Purification Cooling System
Specifications
Brand Name :
HUAYU
Model Number :
HYBM3000-9
Certification :
ISO9001 CE
Place of Origin :
CHINA
MOQ :
1 SET
Price :
440000 USD
Payment Terms :
L/C,T/T
Supply Ability :
1SET 120DAYS
Delivery Time :
4 MONTHS
Packaging Details :
be disassembled into many parts for container transportation
Machine Dimension :
8.5*6*7.2
Color :
customied
Layer :
2 layers
Product Range :
1000L
Total Power :
560kw
Showroom Location :
None
Material :
HDPE
Cooling Water Pressure :
0.3-0.6MPa
Range :
1000L IBC TANK
Automation :
Automatic
Machinery Test Report :
Provided
Touch Screen :
Siemens
Feeding Type :
vacuum feeding
Accumulator Capacity :
35kg
Mian Oil Pump :
gear pump160cc
Description

Focused on sustainability, this 3000L capacity blow molding machine with 9-layer co-extrusion features a water tank system that ensures clean and efficient cooling water circulation. This eco-friendly design reduces environmental impact and enhances the machine's longevity. The machine is equipped with advanced technologies for precise temperature control and consistent product quality, making it an excellent choice for environmentally conscious manufacturers. The water tank is designed for easy maintenance and long-term reliability, making this machine a cost-effective and efficient solution for your production needs.

die head

Accumulator capacity

150kg

designed by ourselves and get the patent

Die diameter

According to products

ie head heating power

160kw

Clamping System

platen size

2400*2500*70mm(W*H*T)

smooth running, no noise; the clamping force is big

clamping cylinder

350+200*2

clamping cylinder stroke

2200mm

clamping force

3000KN

distance between platens

1600-4000mm

max. mould size

1800*2500mm(W*H)
