3000L 6-Layer Large Economical Water Tank Blow Molding Machine with Energy-Saving Design
3000L 6-Layer Large Economical Water Tank Blow Molding Machine with Energy-Saving Design
3000L 6-Layer Large Economical Water Tank Blow Molding Machine with Energy-Saving Design
3000L 6-Layer Large Economical Water Tank Blow Molding Machine with Energy-Saving Design
3000L 6-Layer Large Economical Water Tank Blow Molding Machine with Energy-Saving Design
3000L 6-Layer Large Economical Water Tank Blow Molding Machine with Energy-Saving Design
3000L 6-Layer Large Economical Water Tank Blow Molding Machine with Energy-Saving Design
3000L 6-Layer Large Economical Water Tank Blow Molding Machine with Energy-Saving Design
Specifications
Brand Name :
HUAYU
Model Number :
HYBM3000-6
Certification :
ISO9001 CE
Place of Origin :
CHINA
MOQ :
1 SET
Price :
410000 USD
Payment Terms :
L/C,T/T
Supply Ability :
1SET 120DAYS
Delivery Time :
4 MONTHS
Packaging Details :
be disassembled into many parts for container transportation
Motor :
Siemens
Capacity Range :
500--3000L,4layers
Screw Diameter :
100mm*8
Attribute :
Drawings customize
Condition :
New
Production Speed :
500-600 bottles per hour
Productivity :
16-25pcs/h
Recyclability :
Recyclable
Application :
Bottle
Bucket Thickness :
not very thick
Machine Dimension :
9*10*7.5
Control Sysytem :
moog+plc
Extruder Motor :
55/75/55kw
Mould Material :
Steel
Max. Mould Size :
2000mm x 1200mm
Description

This economical blow molding machine with a 3000L capacity and 6-layer co-extrusion is designed for cost-effective production. The water tank system ensures efficient cooling and heat dissipation, maintaining optimal operating temperatures and enhancing production efficiency. The machine's advanced control system offers precise control over the molding process, ensuring consistent product quality. Its durable construction and reliable performance make it suitable for small to medium-scale production environments. The water tank is designed for easy maintenance and long-term reliability, making this machine a cost-effective and efficient solution for your production needs.

Extrusion System

Screw diameter

100/130/100mm

Nitrided 38CrMoAIA

Screw L/D ratio

28:1

special designed screw can ensure the material plasticizing uniform and efficient

Extruder motor

55/110/55kw

Reducer

280/375/280

Best quality brand in china ,long life and low noise

Screw heating power

5kw*15

Plasticizing capacity

700kg/h

die head

Accumulator capacity

90kg

designed by ourselves and get the patent

Die diameter

According to products

Die head heating power

110kw
