3000L 1-Layer Large Basic Water Tank Blow Molding Machine for Basic Production
3000L 1-Layer Large Basic Water Tank Blow Molding Machine for Basic Production
3000L 1-Layer Large Basic Water Tank Blow Molding Machine for Basic Production
3000L 1-Layer Large Basic Water Tank Blow Molding Machine for Basic Production
3000L 1-Layer Large Basic Water Tank Blow Molding Machine for Basic Production
3000L 1-Layer Large Basic Water Tank Blow Molding Machine for Basic Production
3000L 1-Layer Large Basic Water Tank Blow Molding Machine for Basic Production
3000L 1-Layer Large Basic Water Tank Blow Molding Machine for Basic Production
Specifications
Brand Name :
HUAYU
Model Number :
HYBM3000-1
Certification :
ISO9001 CE
Place of Origin :
CHINA
MOQ :
1 SET
Price :
260000 USD
Payment Terms :
T/T,L/C
Supply Ability :
1SET 120DAYS
Delivery Time :
4 MONTHS
Packaging Details :
be disassembled into many parts for container transportation
Screw Material :
38CrMoAlA，Nitriding
Automation Level :
Fully Automatic
Plasticizing Capacity :
400kg/h
Bucket Thickness :
not very thick
Applicable Material :
HDPE
Water Pressure :
0.3MPa
Air Supply :
0.8*6(Mpa*Cubic meter per minute)
Production Speed :
100-200 pcs/h
Clamping Cylinder :
320+160*2
After Sales :
OVERSEAS SERVICE
Machine Demesion :
8.5*6*7.2
Product Range :
Plastic Bottle Jerrycan
Hollow Part Volume :
500-2000L
Capacity :
1000-5000 Liters
Machine Size :
5.0x2.3x3.6M
Description

This basic blow molding machine with a 3000L capacity and 1-layer co-extrusion is designed for fundamental production needs. The water tank system ensures efficient cooling and heat dissipation, maintaining optimal operating temperatures and enhancing production efficiency. The machine's straightforward design and reliable performance make it suitable for small to medium-scale production environments. Its advanced control system offers precise control over the molding process, ensuring consistent product quality. The water tank is designed for easy maintenance and long-term reliability, making this machine a cost-effective and efficient solution for your production needs.

blowing and cooling system

stretching stroke

according to products

blow pin up/down stroke

600mm

air seat stroke

400mm

maximum air pressure

0.8Mpa

air consumption

3m3/min

Cooling method

Circulating water

Water pressure

0.3MPa

Cooling water consumption

75m3/h

Hydraulic system

main oil tank capacity

1500L

Servo motor, less energy consumption, high efficiency, low noise

main oil pump

gear pump185CC

main oil pump motor

70kw

Servo oil tank capacity

200L

Servo oil pump model

Plunger pump22

Servo oil pump motor

7.5kw
