Specifications
MOQ :
12
Price :
US$165.00~US$359.00
Brand Name :
WINTACT,BESTONE
Model Number :
WT3090,WT3160,WT3220,WT3320
Certification :
CE,ROHS,FC,FDA
Place of Origin :
CHINA
Payment Terms :
T/T,Western Union
Supply Ability :
More than 500pcs per month
Delivery Time :
3-5 working days
Packaging Details :
Color paper box
Model NO. :
WT3090/3160/3220/3320
Standard :
Celsius/Fahrenheit
Accuracy :
+/-2 Celsius
Usage :
Industrial, Household, Laboratory
Display :
Digital
Transport Package :
Carrying Box
Trademark :
BESTONE
Origin :
China
HS Code :
9015800090
Description
WT Series Professional Infrared Thermal Imaging Cameras
WT3090, WT3160, WT3220, WT3320 Thermometer - Handheld Professional Infrared Thermal Imaging Camera with 320*240 Resolution, Temperature Range -20°C to +550°C
Product Overview
Thermal imagers are designed for non-contact detection and calculation of apparent surface temperature, with thermal image creation based on temperature variation. These imager thermometers provide fast and accurate readings for most surface temperature measurements with TFT color LCD display and imager video format. Built for tough work environments, these high-performance, fully radiometric imagers are ideal for troubleshooting electrical systems, electro-mechanical equipment, process equipment, HVAC/R equipment and other industrial applications.
Key Features
  • Compact design with easy operation and robust functionality - ideal for electric power, electronic manufacturing, and industrial inspection applications
  • Integrated visible light camera with simultaneous storage of thermal and visible images accessible via USB
  • Adjustable radiation coefficient for enhanced measurement accuracy on semi-reflective surfaces
  • High/low temperature cursor guidance to identify hottest and coldest areas within thermal images
  • Multiple selectable color palettes for optimal visualization
  • Video recording capability for comprehensive analysis
  • Included analysis software for detailed thermal data processing
Technical Specifications
Parameter WT3090 WT3160 WT3220 WT3320
Infrared Image Resolution 120*90 160*120 220*160 320*240
Temperature Measurement Range -20°C to 550°C (-4°F to 1022°F)
FOV/Shortest Focal Length 26°*19″/0.5m 35°*26″/0.5m 35°*26″/0.5m 56°*42″/0.5m
Measurement Accuracy -15°C to 550°C: ±2°C or ±2%; -20°C to 15°C: ±4°C
Display Screen 2.8" full-angle TFT display screen
Visible Image Resolution 300,000 pixel
LCD Resolution 320*240
Thermal Sensitivity ≤40mK (@25°C, F#1.0) <50mK (@25°C, F#1.0)
Emissivity Adjustable from 0.01 to 1.00
Frame Rate of Thermal Images 25Hz
Wavelength Coverage 8-14μm
Focus Mode Fixed
Color Palette Spectra, Iron, Cool, White Hot, Black Hot
Storage Capacity Built-in 8GB (approximately 6.62GB available)
File Format JPG
USB Interface Type-C
Power Supply Built-in rechargeable 18650 battery
Working Time 2-3 hours
Automatic Power-off Selectable: 5 min / 20 min / No auto power-off
Operating Temperature -20°C to 50°C
Storage Temperature -20°C to 60°C
Storage Humidity 40% to 75%
Languages English, Chinese, Italiano, Deutsch, Russian
