GT5307A 1000V DC Voltage Insulation Resistance Tester Digital Ohm Meter with LCD Back-light
GT5307A 1000V DC Voltage Insulation Resistance Tester Digital Ohm Meter with LCD Back-light
GT5307A 1000V DC Voltage Insulation Resistance Tester Digital Ohm Meter with LCD Back-light
GT5307A 1000V DC Voltage Insulation Resistance Tester Digital Ohm Meter with LCD Back-light
GT5307A 1000V DC Voltage Insulation Resistance Tester Digital Ohm Meter with LCD Back-light
GT5307A 1000V DC Voltage Insulation Resistance Tester Digital Ohm Meter with LCD Back-light
GT5307A 1000V DC Voltage Insulation Resistance Tester Digital Ohm Meter with LCD Back-light
GT5307A 1000V DC Voltage Insulation Resistance Tester Digital Ohm Meter with LCD Back-light
GT5307A 1000V DC Voltage Insulation Resistance Tester Digital Ohm Meter with LCD Back-light
GT5307A 1000V DC Voltage Insulation Resistance Tester Digital Ohm Meter with LCD Back-light
Specifications
MOQ :
10
Price :
EXW US$35
Brand Name :
Benetech, Bestone
Model Number :
GT5307A
Certification :
CE, FCC, RoHS
Place of Origin :
CHINA
Payment Terms :
T/T,Western Union
Supply Ability :
More than 500pcs per month
Delivery Time :
3-5 working days
Packaging Details :
Color paper box and cloth bag
Model NO. :
GT5307A
Rated Voltage :
250V / 500V /1000V
Measure Range 1 :
250V and 500V: 1-200mΩ
Measure Range 2 :
1000V: 10-2000mΩ
Accuracy :
±10%Rdg, ±5%Rgt
Transport Package :
Box and Carrying Bag
Specification :
CE, ROHS
Origin :
China
Description
GT5307A AC Voltage Insulation Resistance Tester Digital Ohm Meter High Tension Megger
Product Overview

The GT5307A 1000V Voltage Insulation Resistance Tester is a professional digital ohm meter and high tension megger designed for comprehensive insulation resistance testing. This advanced instrument utilizes a low-loss, high-change ratio inductive energy storage DC voltage converter to transform 9V input into 250V/1000V DC output, combined with a digital electric bridge for precise resistance measurement.

Ideal for insulation resistance testing requirements across various applications including motors, cables, electromechanical equipment, telecommunication systems, and power facilities. Features ergonomic two-handed operation with strap, backlight display, data hold function, and stable performance in a compact, professional design.

Key Features
  • Insulation Resistance Measurement
  • AC Current Measurement
  • DC Current Measurement
  • Small Resistance Measurement
  • Measured Data Holding Function
  • Low Battery Indication
  • LCD Back-light Display
  • External DC Power Supply (DC9V 1.5A)
  • Over-limit Alarm System
  • Red Alarm Light with Buzzer
  • High Voltage Alarm
Performance Parameters
  • Accuracy: ±(a% + least significant digit)
  • Environment temperature for accuracy: 23±5℃
  • Relative humidity: <75%
  • Calibration guarantee period: 1 year from manufacture date
  • Voltage input impedance: 1MΩ
  • AC voltage frequency response: 50~200Hz

Specification:

Technical specifications

Technical Index

Display

3.5 digit LCD, maximum reading "1999"

Over limit indication

When the upper limit is exceeded, only the top digit will display "1"

Sampling Rate

About 3 times/second

Allowable altitude

<2000 meters

Operating Environment

For indoor use, pollution degree 2

Operation Environment

-15℃~55℃, relative humidity <75%RH

Storage Environment

-40℃~60℃, relative humidity <90%RH

Overload Protection

100mA/60V resettable fuse

Low Battery Indication

The symbol appears on the screen

Power Supply

6×1.5V "AA" batteries or external DC 9V power supply

Current Consumption

No-load power consumption <300mW when testing

Dimension

176×110×77mm

Weight

580g (including battery)

Basic Function:

Basic Function

Measuring Range

Basic Accuracy

Output Voltage

250V / 500V / 1000V

±10%

Test Current

250V (R=250kΩ) 1mA

500V (R=500kΩ) 1mA

1000V (R=1MΩ) 1mA

±10%

Insulation Resistance

250V: 1MΩ ~ 200MΩ

500V: 1MΩ ~ 200MΩ

1000V: 10MΩ ~ 2000MΩ

± (4%±2)

Short-circuit Current

< 1.8mA

—

Median Resistance

250V / 500V: 100MΩ

1000V: 1000MΩ

—

Resistance, Continuity Test

0Ω ~ 2kΩ, buzzer sounds when <50Ω, Test Current: 1mA

± (0.8%±6)

DC Voltage Measurement

0V ~ 1000V

± (0.5%±6)

AC Voltage Measurement

0V ~ 750V

± (1%±6)

Jack Position

Insulation Resistance: E and L

Voltage, Resistance: V/Ω and G

—

Further explanation Median resistance——the lower limit of resistance measurement to ensure that the voltage at both ends of the measurement is not less than 90% of the nominal value of the test voltage.

The contents included in the shipment:

  1. Insulation Resistance tester x 1pcs.
  2. 10A Test pen x 2pcs.
  3. Crocodile clip x 2pcs.
  4. Strap x 1pcs.
  5. 1.5V AA Size batteries x 6pcs.
    (International shipping not included)
  6. User's manual x 1pcs.
  7. Cloth bagx1pc.
  8. Color paper box x1pc.
