HT-H101,HT-H100 Handheld Infrared Thermal Imager
HT-H101,HT-H100 Handheld Infrared Thermal Imager
HT-H101,HT-H100 Handheld Infrared Thermal Imager
HT-H101,HT-H100 Handheld Infrared Thermal Imager
HT-H101,HT-H100 Handheld Infrared Thermal Imager
HT-H101,HT-H100 Handheld Infrared Thermal Imager
HT-H101,HT-H100 Handheld Infrared Thermal Imager
HT-H101,HT-H100 Handheld Infrared Thermal Imager
HT-H101,HT-H100 Handheld Infrared Thermal Imager
HT-H101,HT-H100 Handheld Infrared Thermal Imager
Specifications
Brand Name :
Bestone, HTI
Model Number :
HT-H101,HT-H100
Certification :
CE,ROHS,FC
Place of Origin :
CHINA
MOQ :
100
Price :
EXW US$125~US$85
Payment Terms :
T/T,Western Union
Supply Ability :
More than 10000pcs per month
Delivery Time :
3-5 working days
Packaging Details :
Blister packaging+color card
Frame rate :
≤18Hz (HT-H101), ≤25Hz (HT-H100)
Infrared resolution :
96x96 ISR (240x240)
Field angle :
50°(H)×50°(V)
Measuring range :
-20℃~550℃ (-4°F~1022°F)
Spectral range :
8~14μm
Product weight :
249.5g
Description

Applications:
Infrared thermal imaging cameras are widely used in many fields such as medical, public security, fire protection, archaeology, transportation, agriculture and geology. It is an ideal choice for electricians and maintenance technicians to quickly locate problem areas.
HT-H101,HT-H100 Handheld Infrared Thermal Imager

Features:
1. Lightweight and easy to carry.

2. Field of view Angle/focal length: 50.0°50°/1.35MM.
3. wavelength range 8 to 14 μm.
Specification:

Model

HT-H101

HT-H100(new)

Frame rate

≤18Hz

≤25Hz

Temperature measurement mode

Center point/cold hot spot tracking

Center point/highest/lowest temperature

Focusing mode

Free focus

Fixed focus

IFOV

8.89mard

no

Image display mode

Infrared/visible/dual light fusion

Infrared

Storage capacity

Built-in 8G (User available storage space is about 6.5G)

Built-in 128M FLASH (with space available for the user at about 50M)

File format

JPG/MP4

JPG

Detector Type

Vox

Infrared image resolution

96x96 ISR (240x240)

Field angle

50°(H)×50°(V)

NETD

≤60mK@25°C, F#1.0

Measuring range

-20℃~550℃(-4°F~1022°F)

Spectral range

8~14μm

Pixel spacing

12μm

Focal length

1.35mm

Emissivity

0.01~1.00

Measurement accuracy

±2°C or ±2%(maximum)

Temp. measurement resolution

0.1°C

Palettes

Rainbow/Iron red/red heat/white heat/black heat

Display screen

2.4 inches (240x320)

Image/video export the schema

USB connection computer export

Image analysis function

Supports PC offline analysis

Language

Chinese, English, German, Italian

Other Specifications

Model

HT-H101

HT-H100

Battery type

Built-in Chargeable lithium battery (18650)

Removable Chargeable lithium battery (18650)

Battery capacity

2000mAh

1000mAh

Working time

4 hours

≥ 3 hours

Storage Temperature

-20℃~+60℃(-4°F~140°F)

-10℃ ~ +50℃

Work temperature

-5℃+40℃(-4°F-104°F)

Relative humidity

10% to 85% RH (non-condensation

Product weight

249.5g

Product size

208mmx60.9mmx75.9mm
