SM6807PLUS High Precision 0.01°C RTD Thermometer with Wide Temperature Range -100°C to 300°C and Data Recording 84 Groups
SM6807PLUS High Precision 0.01°C RTD Thermometer with Wide Temperature Range -100°C to 300°C and Data Recording 84 Groups
SM6807PLUS High Precision 0.01°C RTD Thermometer with Wide Temperature Range -100°C to 300°C and Data Recording 84 Groups
SM6807PLUS High Precision 0.01°C RTD Thermometer with Wide Temperature Range -100°C to 300°C and Data Recording 84 Groups
Specifications
Resolution :
0.01℃ (-100.00℃~199.99℃), 0.1℃ (200℃~300℃)
Certification :
CE,ROHS
Measuring range :
-100.00℃~199.99℃, 200.0℃~300.0℃
Model Number :
SM6807PLUS
Sampling rate :
2.5 times/sec
MOQ :
2
Delivery Time :
5-8 working days
Data recording :
84 groups
Payment Terms :
T/T
Packaging Details :
Plastic carrying case and white paper box
Accuracy :
±(0.05% +0.1℃)
Place of Origin :
CHINA
Display type :
4 1/2-digit High brightness VA green screen display
Brand Name :
Bestone
Description
SM6807PLUS RTD Thermometer
Product Overview

This high-precision platinum resistance thermometer delivers exceptional reliability across a wide temperature measurement range with accuracy of 0.01°C. Constructed from high-strength ABS material with a detachable protective sleeve, it effectively minimizes damage from impacts or drops.

The probe-to-instrument connection utilizes an aviation-grade connector with spring-loaded locking mechanism, ensuring secure connections while allowing easy attachment and detachment. Designed for high-precision temperature monitoring across multiple sectors including laboratories, food and pharmaceutical industries, household use, general industry, aerospace, and livestock farming.

Important Note: The probe's sensing element is located within the first 10 mm of the tip. For accurate measurement, ensure at least the first 10 mm of the tip is fully immersed in the environment being measured.
Key Features
  • Data hold function
  • Temperature difference measurement
  • Count down-based data logging
  • Min/Max value display
  • High/low temperature limit settings and threshold alarms
  • Manual data logging (up to 84 records)
  • Toggleable auto-power-off function
  • Switchable temperature units: Kelvin, Fahrenheit, and Celsius
  • Dual-color (green/red) display indicating temperature risk levels
  • Designed for food safety monitoring in compliance with HACCP principles
Technical Specifications
Display 4 1/2-digit high brightness VA green screen display
Dual-color (green/red) display indicating temperature risk levels
Measuring Range -100.00℃ to 199.99℃
200.0℃ to 300.0℃
Resolution 0.01℃ (-100.00℃ to 199.99℃)
0.1℃ (200℃ to 300℃)
Accuracy ±(0.05% + 0.1℃)
Sampling Rate 2.5 times/second
Data Recording 84 groups
Power Source 4 AA batteries (for air shipping, not included)
Operating Conditions 0-40℃ (32°F-104°F), 0-70% RH
Storage Conditions -10℃ to 50℃ (14°F-122°F), 0-80% RH
Instrument Size 165 × 75 × 45 mm
Probe Size Wire length: 750 mm
Probe: 285 mm, Handle: 125 mm
Weight 276 g (including battery)
Standard Accessories
Included Items
  • Digital RTD Thermometer
  • Measurement probe
  • Plastic carrying case and white paper box
  • 4 AA batteries (for air shipping, not included)
  • Manual
