SKF 29322 E Spherical Roller Thrust Bearing - 110 mm Bore, 190 mm OD, 48 mm Width,Self Aligning; Not Banded; Steel Cage
SKF 29322 E Spherical Roller Thrust Bearing - 110 mm Bore, 190 mm OD, 48 mm Width,Self Aligning; Not Banded; Steel Cage
SKF 29322 E Spherical Roller Thrust Bearing - 110 mm Bore, 190 mm OD, 48 mm Width,Self Aligning; Not Banded; Steel Cage
SKF 29322 E Spherical Roller Thrust Bearing - 110 mm Bore, 190 mm OD, 48 mm Width,Self Aligning; Not Banded; Steel Cage
Specifications
Brand Name :
SKF
Model Number :
29322 E
MOQ :
1
Price :
USD 0.5-10 PCS
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
1000 PCS/MON
Delivery Time :
3-15 DAYS
Packaging Details :
Single Box , Industrial Packing
Precision rating :
P0 P6 P5 P4 P2
Material :
Chrome Steel
Cage :
Steel,Brass
Package :
Original Package
Description

SKF 29322 E Spherical Roller Thrust Bearing

FEATURES

  • Accommodates heavy combined load at high speeds
  • Unaffected by misalignment
  • Self-aligning
  • Separable design

DIMENSIONS

d
110 mm
 Bore diameter
D
190 mm
 Outside diameter
H
48 mm
 Nominal Height
d1
≈171 mm
 Outside diameter of shaft washer end side face
D1
≈140 mm
 Shoulder diameter outer ring
B
30.3 mm
 Width shaft washer or length of shaft washer bore diameter that fits on shaft (bearings with a stamped steel cage)
B1
41.7 mm
 Height shaft washer + cage
C
24.8 mm
 Height housing washer
s
63.8 mm
 Distance from shaft washer end side face to pressure point
r1,2
min.2 mm
 Chamfer dimension shaft washer

ABUTMENT DIMENSIONS

da
min.145 mm
 Abutment diameter shaft
db1
max.117 mm
 Abutment diameter spacer ring (E design bearings)
db2
max.117 mm
 Abutment diameter spacer ring (E design bearings)
Da
max.164 mm
 Abutment diameter housing
ra
max.2 mm
 Fillet radius

CALCULATION DATA

Basic dynamic load rating C
610 kN
Basic static load rating C0
1 730 kN
Fatigue load limit Pu
204 kN
Reference speed
1 900 r/min
Limiting speed
3 200 r/min
Minimum axial load factor A
0.28

MASS

Mass bearing
5.3 kg

SKF 29322 E Spherical Roller Thrust Bearing - 110 mm Bore, 190 mm OD, 48 mm Width,Self Aligning; Not Banded; Steel Cage SKF 29322 E Spherical Roller Thrust Bearing - 110 mm Bore, 190 mm OD, 48 mm Width,Self Aligning; Not Banded; Steel Cage

Product Picture

SKF 29322 E Spherical Roller Thrust Bearing - 110 mm Bore, 190 mm OD, 48 mm Width,Self Aligning; Not Banded; Steel CageSKF 29322 E Spherical Roller Thrust Bearing - 110 mm Bore, 190 mm OD, 48 mm Width,Self Aligning; Not Banded; Steel Cage

Packing , Payment , Delievry and Stock

Packaging
1)Commercial Bearings packaging: 1pc/plastic bag + color box + carton + pallet
2)Industrial Bearings packaging a)plastic tube + carton + pallet
b). plastic bag +kraft paper + carton + pallet
3)According to the requirement of customers'
Payment
1) T/T:30% deposit, 70% should be paid before shipment.
2) L/C at sight. (high bank charge, not suggest, but acceptable )
3) 100% Western Union in advance. (especially for air shipment or small amount)
Delivery
1) Less than 45 KGS, we will send by express. ( Door to Door, Convenient )
2) Between 45 - 200 KGS, we will send by air transport. ( Fastest and safest, but expensive )
3) More than 200 KGS, we will send by sea. ( Cheapest, but long time )
Stock
1)Availability and supply capacity on a certain basis
