Electrode Cutting Machine Die Cutting Machine Continuous Coating Rolls Honbro
Electrode Cutting Machine Die Cutting Machine Continuous Coating Rolls Honbro
Specifications
Brand Name :
Honbro
Place of Origin :
Dongguan China
MOQ :
1 set
Payment Terms :
T/T, D/A, L/C, D/P, Western Union, MoneyGram
Price :
negotiation
Supply Ability :
350 sets/year
Delivery Time :
13-14 weeks
Packaging Details :
Fumigation-free wooden box + vacuum moisture-proof treatment
Certification :
CE certification
Output :
≥40PPM
Min cutting forming size :
L 60 (include tab) x W 50mm
Burr :
Horizontal, vertical ≤ 0.015mm
Cutting Die life Anode Die once life :
Anode Die once life ≥ 1.2 million times, can be repaired 10 times, total life ≥ 12 million times
Description

Electrode Die Cutting Machine With Continuous Coating Rolls , Electrode Making

an all-in-one machine with a variety of coating options to meet different coating process needs. It is mainly used for the surface coating process for lithium battery Cathode and Anode, and it is an experimental coating equipment with high precision and stability. The device can realize two methods of slot die extrusion coating and comma bar coating by switching the coating mode and the coating head assembly,continuous coating and intermittent coating can be achieved. Reserve test communication interface or test system with thickness/surface density; Electrode tension control, constant tension unwinding, constant tension coating, drying; System parameters are centrally controlled, the man-machine interface adopts touch screen and keystroke mode, and hierarchical control, and process parameters can be locked, stored and called.

Technical Parameters

Item Common parameter
Output ≥40PPM
Min cutting forming size L 60 (include tab) x W 50mm
Burr Horizontal, vertical ≤ 0.015mm
Electrode shape accuracy ±0.2mm
Tab to electrode coating side edge accuracy ±0.4mm
Tab powder accuracy ±0.4mm
Cutting Die life Anode Die once life ≥ 1.2 million times, can be repaired 10 times, total life ≥ 12 million times
Cathode Die once life ≥ 0.8 million times, can be repaired 10 times, total life ≥8 million times
EMS function It can dock with MES system
Action 95%
Qualification rate 98%

Function Description

  • The equipment is mainly used for cutting and forming the continuous coating rolls of lithium ion batteries into anode & cathode electrode sheets.
  • Optional configuration: CCD visual material with defect detection, defective product labeling detection, FFU clean air dust removal system, non-contact dust removal
