500℃ Round Electric Heating Die
500℃ Round Electric Heating Die
Specifications
Brand Name :
TICO
Model Number :
STC-RYM-RZ12
Place of Origin :
Shenzhen, China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
30 sets per month
Delivery Time :
7~8 working days
Packaging Details :
Standard export wooden packing
Product Name :
500℃ Round Electric Heating Die
Voltage :
AC 220V±10%, 50 Hz
Power :
400W
Die heating range :
Rt ~ 500℃
Die diameter :
12mm
Heating core outer diameter :
43mm
Chamber depth :
40mm
Intelligent thermostat dimension :
L230 * W270 * H180mm
Weight :
3.5KG
Description

500℃ Round Electric Heating Die

Brief Introduction

This product is suitable for pressing and molding samples under high-temperature conditions. It features compact size, fast heating speed, and high temperature capability (up to 500°C). Equipped with a 7-inch touchscreen intelligent temperature controller, it supports multi-stage temperature control, meeting the high-temperature and high-pressure sample preparation requirements for various materials.


Technical Parameters

Model

STC-RYM-RZ12

Voltage

AC 220V±10%, 50 Hz

Heating jacket power

400W

Die heating range

Rt ~ 500℃

Die diameter

12mm

Heating core outer diameter

43mm

Heating jacket outer diameter

78mm

Chamber depth

40mm
Pressure control accuracy

0.1T (Customizable self-setting accuracy)

Holding time

No time limit, reach the set time to stop heating

Display mode

7 inch touch LCD screen (more convenient operation)

Intelligent thermostat temp control range

Rt ~ 800℃
Intelligent thermostat temp control mode

5 sections adjustable continuous, segmented temperature control

Dimension

L230 * W270 * H180mm

Weight

3.5kg


Warranty

1 year's warranty with lifetime technical support.

FAQ

1. Are you a manufacture ?

A: Yes,our factory is located in Shenzhen, China.

We have more than 10 years experience for manufacturing battery lab research equipment. We owns a professional R&D department.

2. Do you accept customized product ?

A: Yes. Most of our products can be customized to meet different requirments.

3. Will you provide test video before dispatch ?

A: Yes, we take test video for every equipment before dispatchm which will display how to use it.

4. Can you offer overseas installation service ?

A: Yes, we can dispatch professional engineer for on-site installion service.
