4 Paths Film Applicator with Fixed Thickness
4 Paths Film Applicator with Fixed Thickness
Specifications
Brand Name :
TICO
Model Number :
STC-TMQ-1004
Place of Origin :
Shenzhen, China
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
300 sets per month
Delivery Time :
4~7 days
Packaging Details :
Carton Box
Product Name :
4 Paths Film Applicating Device
Coating Thickness :
5um-10um-15um-20um
Coating width :
80mm
Material :
corrosion resistance material
Feature :
Fixed with
Applicable material :
stainless steel plate, plastic plate, wooden plate, etc.
Description

4 Paths Film Applicator with Fixed Thickness

Brief Introduction

It is fixed thickness precision film applicator with four paths for lab small qty coating, various of thickness can be optional. The doctor blade width is 100mm, effective coating width is 80mm.

Key Features

● Fixed width with high precision.

● Different thickness can be optional.

● Multiple application, it is suitable for various film coating.

● Small size, it is an ideal device for making small quantity coating research.

Technical Parameters

Model STC-TMQ-1004
Thickness specification

5μm-10μm-15μm-20μm

10μm-15μm-20μm-25μm

25μm-50μm-75μm-100μm

30μm-60μm-90μm-120μm

50μm-100μm-150μm-200μm

50μm-75μm-100μm-150μm

100μm-200μm-300μm-400μm

100μm-150μm-200μm-250μm

250μm-500μm-750μm-1000μm
Effective coating width 80mm
Material Corrosion resistance material

Warranty

1 year warranty with lifetime support. Man-made damage is not covered.

FAQ

1. Are you a manufacturer?

A: Yes, our factory is located in Shenzhen, China.
We have more than 10 year experience for manufacturing battery lab research equipment. We own a professional R&D department.

2. Do you accept customized product?

A: Yes. Most of our products can be customized to meet different requirements.

3. Will you provide test video before dispatch?

A: Yes, we take test video for every equipment before dispatch, which will display how to use it.

4. Can you offer overseas installation service?

A: Yes, we can dispatch professional engineer for on-site installation service.
